Transmission | PRO-TORQ CVT with Quick Response System (QRS), high-airflow ventilation and Electronic Drive Bel |
Transmission Type | Belt |
Clutch | PASC™ antihopping clutch, mechanically operated |
Gearbox | 6-speed |
Chain Type | 520 X-Ring |
Gear Ratios 2nd | 6.411 : 1 |
Gear Ratios 1st | 9.403 : 1 |
Gear Ratios 3rd | 4.763 : 1 |
Gear Ratios 4th | 3.796 : 1 |
Gear Ratios 5th | 3.243 : 1 |
Gear Ratios 6th | 2.789 : 1 |
Front Suspension | Double A-arm |
Rear Suspension | TTA with external sway bar |
Front Travel | 6.7 in (170 mm) |
Rear Travel | 6.7 in (170 mm) |
Front Shocks | Twin tube gas-charged shocks |
Rear Shocks | Twin tube gas-charged shocks |
Front Braking System | Dual 220 mm disc brakes with hydraulic twin-piston calipers |
Rear Braking System | Dual 220 mm disc brakes with hydraulic single-piston calipers |
Parking Brake | Park In-Transmission / Lockable Hand Lever |
Wheels | 14 in. cast aluminum | Steering: Adjustable tilt steering |
Front Tire | XPS Trail Force 27 x 9 / 11 x 14 in. |
Rear Tire | XPS Trail Force 27 x 9 / 11 x 14 in. |
Front Wheel | Rims: 6-spoke, 15 x 5 in. (381 x 127 mm) |
Rear Wheel | Rims: 6-spoke, 15 x 7 in. (381 mm x 178 mm) |
Wheelbase | 83 in (2,115 mm) |
Ground Clearance | 11 in (280 mm) |
Bed Box Dimensions | 26 x 17.7 x 11.5 in (66 x 45 x 29.2 cm) |
Overall Vehicle Size | 47.4" w x 82.8" l x 46.2" h |
Seat Height | 33.6 in (853 mm) |
Rake / Trail | 27.5° / 4.3" |
Lean Angle (Left) | 28.5 |
Lean Angle (Right) | 28.5 |
Cargo System | 4 Gal (15 L) Front Dry Storage 2 Gal (8 L) Rear Storage |
Payload Capacity | 680 lbs (1,500 kg) |
Fuel Capacity | 10.6 gal (40 L) |
Box Capacity | 300 lb (136 kg) |
Cargo Capacity | 454 lbs (1,000 kg) |
Storage Capacity | 10.4 gal (39.5 L) |
Hitch Type | 2 in. hitch receiver |
Hitch Capacity | 1,500 lb (680 kg) |
Rack Capacity (Front) | 33 pounds |
Rack Capacity (Rear) | 66 pounds |
Seating Capacity | 0 |
Bed Capacity | 1000 pounds for 49- state models; 600 pounds for CA model |
Towing Capacity | 1,134 lbs (2,500 kg) |
Rack Capacity | 200 lb (90 kg) |
Dry Weight | 1,541 lbs (699 kg) |
Gauges | 4.5 in. wide digital display |
Magneto | 650 W |
Audio System | Includes 4 Standard 50 watt speakers. 2 in the fairing, 2 in the trunk. 200 watts total. |
Features | Other Standard: Painted Plastics |
Lighting | Front lighting output 140 W LED tail lights |
Instrumentation | DC outlet (10 A) |
Warranty | Factory: 1 year BRP limited warranty | Extended: B.E.S.T. term available up to 30 months |
Steering | Power: Dynamic Power Steering (DPS) |
Handlebars | Neken, aluminium 28/22 mm |
Cage Type | Profiled cage, ROPS approved |
