| Transmission | pDrive primary CVT L / H / N / R / P |
| Gearbox | Automatic |
| Chain Type | 520 X-Ring |
| Clutch | PASC antihopping clutch, mechanically operated |
| Transmission Type | Chain (final drive) |
| Gear Ratios 1st | 9.403 : 1 |
| Gear Ratios 2nd | 6.411 : 1 |
| Gear Ratios 3rd | 4.763 : 1 |
| Gear Ratios 4th | 3.796 : 1 |
| Gear Ratios 5th | 3.243 : 1 |
| Gear Ratios 6th | 2.789 : 1 |
| Front Suspension | Independent Double Wishbone |
| Rear Suspension | Independent |
| Front Travel | 2.8 in (71 mm) |
| Rear Travel | 2.9 in (74 mm) |
| Front Shocks | Twin tube |
| Rear Shocks | Twin tube |
| Front Braking System | Dual Hydraulic Disc |
| Rear Braking System | Dual Hydraulic Disc |
| Parking Brake | Park In-Transmission |
| Front Tire | 25 x 8/10 x 12 in. |
| Rear Tire | 25 x 8/10 x 12 in. |
| Wheels | 12 in. Steel |
| Front Wheel | 5-spoke, Deep Black, machined and tinted, 16 x 4.5 in. (406 x 114 mm) |
| Rear Wheel | 5-spoke, Deep Black, machined and tinted, 16 x 6.5 in. (406 x 165 mm) |
| Overall Vehicle Size | 68.1" w x 160" l x 76.6" h |
| Rake / Trail | 0° |
| Wheelbase | 53 in (1,345 mm) |
| Seat Height | 38 in (967 mm) |
| Ground Clearance | 12 in (305 mm) |
| Bed Box Dimensions | 43.4 x 56 x 13.4 in (110.2 x 142.2 x 34 cm) |
| Lean Angle (Left) | 31 |
| Lean Angle (Right) | 31 |
| Fuel Capacity | 5.1 gal (19.5 L) |
| Seating Capacity | 0 |
| Hitch Type | 2 in. hitch receiver |
| Hitch Capacity | 3,500 lbs. (1588 kg) |
| Cargo System | Lock & Ride MAX |
| Payload Capacity | 712 lbs (1,570 kg) |
| Rack Capacity (Front) | 120 lb (54.4 kg) |
| Rack Capacity (Rear) | 240 lb (109 kg) |
| Box Capacity | 1,500 lbs. (680 kg) |
| Cargo Capacity | 454 lbs (1,000 kg) |
| Storage Capacity | 9 gal (34 L) |
| Towing Capacity | 830 lbs (1,830 kg) |
| Rack Capacity | 200 lb (90 kg) |
| Bed Capacity | 1,500 lbs. (680 kg) |
| Dry Weight | 750 lbs (340 kg) |
| Gauges | 4.5 in. Digital Display |
| Audio System | Includes 2 Standard 50 watt fairing speakers, 100 watts total. |
| Magneto | 650 W |
| Lighting | LED headlights and tail lights |
| Instrumentation | DC outlet (10-A), USB Port (10-A) x 4 |
| Warranty | 6 / Limited |
| Features | Anti-Theft System: Mechanical key |
| Steering | Power: Tri-Mode Dynamic Power Steering (DPS) |
| Cage Type | Profiled cage ROPS approved |
