Transmission | pDrive primary and Quick Response System X (QRS-X) CVT with high airflow, L / H / N / R / P |
Clutch | Wet, Multi-Plate, Assist |
Gearbox | 6-speed |
Chain Type | O-ring-sealed chain; 14T/36T |
Transmission Type | Chain (final drive) |
Gear Ratios 1st | 10.169:1 |
Gear Ratios 2nd | 6.933:1 |
Gear Ratios 3rd | 5.151:1 |
Gear Ratios 4th | 4.105:1 |
Gear Ratios 5th | 3.508:1 |
Gear Ratios 6th | 3.017:1 |
Front Suspension | Double A-arm with sway bar |
Rear Suspension | 4-link Torsional Trailing-arm X (TTX) with sway bar |
Front Travel | 4.7 in (119 mm) |
Rear Travel | 4.5 in (114 mm) |
Front Shocks | FOX 2.5 PODIUM Piggyback with bypass and Smart-Shox** Technology featuring DDA Valve (Dynamic Damping Adjustment) |
Rear Shocks | FOX 3.0 PODIUM Piggyback with bypass and Smart-Shox** Technology featuring DDA Valve (Dynamic Damping Adjustment) **Smart-Shox was developed in conjunction with Tractive Industries, a market leader in the suspension industry |
Front Braking System | Dual 262 mm disc brakes with hydraulic twin-piston calipers |
Rear Braking System | Dual 248 mm disc brakes with hydraulic twin-piston calipers |
Parking Brake | Park In-Transmission |
Wheels | 14 in. cast-aluminum |
Front Tire | XPS Trac Force 30 x 10 x 14 in. |
Rear Tire | XPS Trac Force 30 x 10 x 14 in. |
Front Wheel | Contrast Cut 19 in x 3.5 in |
Rear Wheel | Contrast Cut 16 in x 5 in |
Overall Vehicle Size | 64" w x 133.3" l x 77.6" h |
Rake / Trail | 28° / 4.3" |
Wheelbase | 135 in (3,429 mm) |
Seat Height | 37.8 in (960 mm) |
Ground Clearance | 13 in (330 mm) |
Lean Angle (Left) | 31 |
Lean Angle (Right) | 31 |
Bed Box Dimensions | 26 x 17.7 x 11.5 in (66 x 45 x 29.2 cm) |
Fuel Capacity | 10.5 gal (40 L) |
Seating Capacity | 0 |
Payload Capacity | 771 lbs (1,700 kg) |
Storage Capacity | 3 gal (11.4 L) |
Rack Capacity | 150 lb (68 kg) with LinQ quick-attach |
Hitch Type | 2 in. hitch receiver |
Hitch Capacity | 1,350 lb (612 kg) |
Cargo System | Lock & Ride |
Rack Capacity (Front) | 120 lb (54.4 kg) |
Rack Capacity (Rear) | 240 lb (109 kg) |
Box Capacity | 300 lb (136 kg) |
Bed Capacity | 600 lb (272 kg) Rear Dumping Box |
Cargo Capacity | 454 lbs (1,000 kg) |
Towing Capacity | 830 lbs (1,830 kg) |
Dry Weight | 1,838 lbs (834 kg) |
Gauges | 7.6 in. digital display with keypad |
Audio System | Includes 4 Standard 50 watt speakers. 2 in the fairing, 2 in the trunk. 200 watts total. |
Magneto | 850-W |
Warranty | Factory: 6-month BRP Limited warranty | Extended: B.E.S.T. term available up to 30 months |
Features | Anti-Theft System: RF Digitally Encoded Security System (D.E.S.S.) with Start/Stop button |
Lighting | LED headlight, LED signature, LED tail lights |
Instrumentation | DC outlet (10-A) |
Steering | Power: High torque Tri-Mode Dynamic Power Steering (DPS) |
Cage Type | Dual-phase 980 steel |
Handlebars | Neken, aluminium 28/22 mm |
