| Transmission | Automatic PVT P/R/N/L/H |
| Chain Type | 2.379:1 |
| Clutch | Multiplate wet clutch; with assist and slipper |
| Gear Ratios 1st | 10.169:1 |
| Gear Ratios 2nd | 6.933:1 |
| Gear Ratios 3rd | 5.151:1 |
| Gear Ratios 4th | 4.105:1 |
| Gear Ratios 5th | 3.508:1 |
| Gear Ratios 6th | 3.017:1 |
| Gearbox | 6-speed |
| Transmission Type | Belt |
| Front Suspension | Light Weight Boxed Dual A-Arm with 3 Piece Stabilizer Bar and 27" (68.6 cm) Usable Travel, 22.25" (56.5 cm) Wheel Travel, Unitized Hubs |
| Rear Suspension | Tubular Trailing Arm with Boxed Gusseting and Toe Link, High Clearance Radius Rods, and Stabilizer Bar and 28.3 in (71.9 cm) *Usable Travel, 22.4 in (56.9 cm) Wheel Travel, Unitized Hubs |
| Front Shocks | Walker Evans 2.5 Velocity Needle Shock with 16-Position Adjustable Clickers |
| Rear Shocks | Walker Evans 3.0 Velocity Needle Shock with 16-Position Adjustable Clickers |
| Front Travel | 5.9 in (150 mm) |
| Rear Travel | 5.7 in (145 mm) |
| Front Braking System | 4-Wheel Hydraulic Disc with Triple-Bore |
| Rear Braking System | 4-Wheel Hydraulic Disc with Dual-Bore Calipers |
| Parking Brake | Park In-Transmission |
| Wheels | 15" Cast Aluminum Rim with 5-Lug Pattern |
| Front Tire | 32 x 10-15 Maxxis Rampage Fury; 8-Ply Rated; Wheel Size 15x7 |
| Rear Tire | 32 x 10-15 Maxxis Rampage Fury; 8-Ply Rated; Wheel Size 15x7 |
| Front Wheel | Metzeler Cruisetec 130/60B19 66H |
| Rear Wheel | 10-Spoke Machined Cast 19" x 3.5" |
| Overall Vehicle Size | 47.4" w x 48.7" h |
| Wheelbase | 96 in (2,440 mm) |
| Seat Height | 32.9 in (836 mm) |
| Ground Clearance | 16 in (406 mm) |
| Rake / Trail | 23.7° / 4" |
| Lean Angle (Left) | 31 |
| Lean Angle (Right) | 31 |
| Bed Box Dimensions | 26 x 17.7 x 11.5 in (66 x 45 x 29.2 cm) |
| Seating Capacity | 3 |
| Storage Capacity | 2.5 gal (9.4 L) |
| Towing Capacity | 830 lbs (1,830 kg) |
| Fuel Capacity | 12 gal (45.4 L) |
| Rack Capacity | 200 lb (91 kg) with LinQ quick-attach |
| Bed Capacity | 299 pounds |
| Rack Capacity (Front) | 120 lb (54.4 kg) |
| Rack Capacity (Rear) | 240 lb (109 kg) |
| Hitch Type | Standard 1.25 in (3.2 cm) Receiver |
| Cargo Capacity | 136 lbs (300 kg) |
| Payload Capacity | 331 lbs (730 kg) |
| Hitch Capacity | 1,350 lb (612 kg) |
| Cargo System | Lock & Ride |
| Box Capacity | 300 lb (136 kg) |
| Dry Weight | 2,142 lbs (972 kg) |
| Gauges | Fairing-mounted instrument cluster featuring analog speedometer and tachometer with fuel gauge, range, odometer and current gear. 15 LED telltale indicators: cruise control enabled, cruise control set, neutral, high beam, turn signal, ABS, check engine, low tire pressure, battery, low fuel, security system, low engine oil pressure and MPH or km/h unit designation. |
| Audio System | Upgraded PowerBand 2.0 Audio package Includes: 2 - 100 watt fairing speakers, 2 - 100 watt saddlebag speakers. 400 watts total. |
| Magneto | 850-W |
| Lighting | Signature Animated RZR Fang Accent Lighting; White LED, Low / High & Red LED Tail / Brake Lights; Interior Dash Accent Lighting |
| Warranty | 12 / Limited |
| Features | Doors: Vented Full Doors | Other Standard: High Output 900W Charging System with Sealed Electrical, Polaris Pulse System, In-Dash Charge Port, Polaris P.A.S.S. |
| Instrumentation | RIDE COMMAND 7 Glove-Touch Display: DYNAMIX 2.0 Visualizer, Built-In GPS, Group ride (cell-based or GPS based), Topographic Mapping, Bluetooth & USB Smartphone Connectivity, AM/FM & Weather Radio, In-Vehicle Communications Capable With Optional Sena Headsets, Polaris P.A.S.S Anti-Theft System. Dual-sweep Analog Dials w/ 4" LCD Rider Information Center: User Selectable Blue/Red Backlighting & Brightness, Programmable Service Intervals. Digital Instrumentation: Speedometer, Tachometer, Odometer, Tripmeter, Clock, Hour Meter, Gear Indicator, Fuel Gauge, Coolant Temperature, Voltmeter, Service Indicator and Codes, Seat Belt Reminder Light, Gear Indicator, DC Outlet |
| Steering | Power: Rack Mounted High Assist Electronic Power Steering with Quick Turn Rack; Race Inspired Steering Wheel with Tilt & Telescoping Adjustment; RIDE COMMAND Push Button Controls |
| Cage Type | Dual-phase 980 steel |
| Handlebars | Aluminum |
Information deemed reliable, but not guaranteed. Interested parties should confirm all data before relying on it to make a purchase decision. All prices and specifications are subject to change without notice. Every price we list INCLUDES destination and assembly (sometimes referred to as freight and set-up), reconditioning, documentation, and dealer handling. The ONLY thing additional you will pay for is accessories, taxes and/or government fees. There are no surprise fees when you pay for your motorcycle, ATV or Side by Side. Please note picture shown may not depict actual unit and may show added accessories that do not come standard.
