Transmission | Automatic PVT P/R/N/L/H |
Transmission Type | Chain (final drive) |
Clutch | Wet, Multi-Plate |
Gearbox | 6-speed |
Chain Type | Chain; 13T/46T |
Gear Ratios 2nd | 1.882 : 1 |
Gear Ratios 1st | 2.769 : 1 |
Gear Ratios 3rd | 1.500 : 1 |
Gear Ratios 4th | 1.273 : 1 |
Gear Ratios 5th | 1.125 : 1 |
Gear Ratios 6th | 0.966 : 1 |
Front Suspension | Long Travel, High Clearance Dual A-Arm with Stabilizer Bar, 14 in (35.6 cm) Travel |
Rear Suspension | Long Travel, High Clearance Dual Arm IRS with Stabilizer Bar, 14 in (35.6 cm) Travel |
Front Shocks | Walker Evans Velocity Series Shocks |
Rear Shocks | Walker Evans Velocity Series Shocks |
Front Travel | 7.3 in (185 mm) |
Rear Travel | 7.3 in (185 mm) |
Front Braking System | 4-Wheel Hydraulic Disc with Dual-Bore Front and Rear Calipers |
Rear Braking System | 4-Wheel Hydraulic Disc with Dual-Bore Front and Rear Calipers |
Parking Brake | Park In-Transmission |
Wheels | 15 in Aluminum |
Front Tire | 30 x 10-15; Pro Armor Crawler XGF |
Rear Tire | 30 x 10-15; Pro Armor Crawler XG |
Front Wheel | Cast 5-Spoke 19" x 3.5" |
Rear Wheel | Cast 5-Spoke 16" x 3.5" |
Seat Height | 33.2 in (845 mm) |
Overall Vehicle Size | 30.9" w x 88.6" l x 43.3" h |
Rake / Trail | 27.5° / 3.7" |
Wheelbase | 83 in (2,110 mm) |
Ground Clearance | 12.5 in (318 mm) |
Bed Box Dimensions | 27.5 x 43.1 x 11.6" (69.8 x 109 x 29.5 cm) |
Lean Angle (Left) | 33 |
Lean Angle (Right) | 33 |
Seating Capacity | 0 |
Fuel Capacity | 9.5 gal (35.9 L) |
Towing Capacity | 830 lbs (1,830 kg) |
Bed Capacity | 1,000 lbs (453.6 kg) |
Hitch Type | Standard 2 in (5.08 cm) Receiver |
Hitch Capacity | 1500 lb (680 kg) |
Cargo System | Lock & Ride |
Payload Capacity | 499 lbs (1,100 kg) |
Box Capacity | 600 lb (272 kg) Rear Dumping Box |
Cargo Capacity | 224 lbs (494 kg) |
Storage Capacity | 3 gal (11.4 L) |
Rack Capacity | 150 lb (68 kg) with LinQ quick-attach |
Rack Capacity (Front) | 90 lb (40.8 kg) |
Rack Capacity (Rear) | 180 lb (81.6 kg) |
Dry Weight | 1,666 lbs (756 kg) |
Gauges | 7.6 in. digital display with keypad |
Magneto | 850-W |
Audio System | Includes 2 Standard 50 watt fairing speakers, 100 watts total. |
Warranty | 12 Month Limited Warranty |
Steering | Power: High torque Tri-Mode Dynamic Power Steering (DPS) |
Features | Doors: Full Doors Standard | Other Standard: POLARIS HD 4500 LB Winch with Synthetic Rope, Aluminum Fairlead & Rubber Isolator, Sport Low Profile Front Bumper, ProFit Sport Roof, Convex Rear View Mirror, Padded Console |
Lighting | LED Headlight w/ Accent & LED Taillights |
Instrumentation | Dual-Sweep Analog Dials with 4" LCD Rider Information Center: User Selectable Blue/Red Backlighting & Brightness, Programmable Service Intervals, Speedometer, Tachometer, Odometer, Tripmeter, Clock, Hour Meter, Gear Indicator, Fuel Gauge, Coolant Temperature, Voltmeter, Service Indicator and Codes, Seat Belt Reminder Light, Gear Indicator, DC Outlet |
Handlebars | Aluminum |
Cage Type | Dual-phase 980 steel |
Headlight Type | LED |
