Transmission | Automatic (CVT) with reverse function |
Transmission Type | Six-speed automatic DCT |
Clutch | Multi-plate with diaphragm spring in oil bath |
Gearbox | 6-speed |
Chain Type | #520 O-ring-sealed chain; 15T/45T |
Gear Ratios 2nd | 6.411 : 1 |
Gear Ratios 1st | 9.403 : 1 |
Gear Ratios 3rd | 4.763 : 1 |
Gear Ratios 4th | 3.796 : 1 |
Gear Ratios 5th | 3.243 : 1 |
Gear Ratios 6th | 2.789 : 1 |
Front Suspension | Double wishbone |
Rear Suspension | Multi-link - mono swing arm |
Front Shocks | KYB HPG with preload ajdustment |
Rear Shocks | KYB HPG with remote reservoir 4-position compression adjustable damping and preload adjustment |
Front Travel | 16 in (406 mm) |
Rear Travel | 18 in (457 mm) |
Front Braking System | 270 mm discs with Nissin 2-piston floating calipers |
Rear Braking System | 220 mm disc, 1-piston floating caliper |
Parking Brake | Park lock |
Wheels | Enforcer Cast Aluminum |
Front Tire | XPS Ride - 145/60 R16 MC 66T |
Rear Tire | XPS Ride - 205/45 R16 MC 77T |
Front Wheel | 5-spoke, Deep Black, machined and tinted, 16 x 4.5 in. (406 x 114 mm) |
Rear Wheel | 5-spoke, Deep Black, machined and tinted, 16 x 6.5 in. (406 x 165 mm) |
Seat Height | 24.7 in (629 mm) |
Overall Vehicle Size | 96.5" length |
Rake / Trail | 26° / 7" |
Wheelbase | 67.3 in (2 mm) |
Ground Clearance | 4 in (101 mm) |
Bed Box Dimensions | 28 x 22 x 7 in (72.0 x 57.0 x 17.8 cm) |
Lean Angle (Left) | 28.5 |
Lean Angle (Right) | 28.5 |
Seating Capacity | 0 |
Fuel Capacity | 5.28 gal (20 L) |
Towing Capacity | 830 lbs (1,830 kg) |
Bed Capacity | 600 lb (272 kg) Rear Dumping Box |
Hitch Type | Standard 2 in (5 cm) Receiver |
Hitch Capacity | 2,500 lb (1,134 kg) |
Cargo System | Lock & Ride |
Payload Capacity | 408 lbs (900 kg) |
Box Capacity | 300 lb (136 kg) |
Cargo Capacity | 199 lbs (438 kg) |
Storage Capacity | 1.85 gal (7 L) |
Rack Capacity | Front: 120 lb (54.4 kg) / Rear: 240 lb (109 kg) |
Rack Capacity (Front) | 120 lb (54.4 kg) |
Rack Capacity (Rear) | 800 lb. (363 kg) |
Dry Weight | 778.2 lbs (353 kg) |
Gauges | 7.6 in. wide digital display |
Magneto | 650 W |
Audio System | Includes 2 Standard 50 watt fairing speakers, 100 watts total. |
Warranty | Factory: 1-year BRP limited warranty with 1-year roadside assistance | Extended Service Terms: B.E.S.T. terms available from 12 to 36 months with roadside assistance |
Steering | Tilt: Standard Tilt |
Features | Main functions: Speedometer, tachometer, odometer, trips, distance to empty, engine lights, fuel gauge, clock, ECO mode and Sport mode. |
Lighting | LED Head Lights & Tail Lights, Illuminated In-Cab Controls |
Instrumentation | 4.5 in. (11,4 cm) digital display |
Handlebars | Aluminum |
Cage Type | Profiled cage, ROPS approved |
Headlight Type | LED |
