| Transmission | Automatic (CVT) with reverse function |
| Chain Type | 2.2 : 1 |
| Clutch | Wet, Multi-Plate |
| Gear Ratios 1st | 9.403 : 1 |
| Gear Ratios 2nd | 6.411 : 1 |
| Gear Ratios 3rd | 4.763 : 1 |
| Gear Ratios 4th | 3.796 : 1 |
| Gear Ratios 5th | 3.243 : 1 |
| Gear Ratios 6th | 2.789 : 1 |
| Gearbox | 6-speed |
| Transmission Type | Automatic PVT F/N/R |
| Front Suspension | Double wishbone |
| Rear Suspension | Multi-link - mono swing arm |
| Front Shocks | KYB HPG with remote reservoir 4-position compression adjustable damping and preload adjustment |
| Rear Shocks | KYB HPG with remote reservoir 4-position compression adjustable damping and preload adjustment |
| Front Travel | 7.3 in (185 mm) |
| Rear Travel | 8.5 in (216 mm) |
| Front Braking System | 270 mm discs with Nissin 2-piston floating calipers |
| Rear Braking System | 220 mm disc, 1-piston floating caliper |
| Parking Brake | Park lock |
| Wheels | Steel |
| Front Tire | XPS Rally - 145/60 R16 MC 66T |
| Rear Tire | XPS Rally - 205/55 R15 MC 81T |
| Front Wheel | 15-spoke, Hyper Silver, 16 x 4.5 in. (406 x 114 mm) |
| Rear Wheel | 15-spoke, Hyper Silver, 15 x 6.5 in. (381 x 165 mm) |
| Wheelbase | 67.3 in (2 mm) |
| Seat Height | 26.6 in (676 mm) |
| Ground Clearance | 4.8 in (122 mm) |
| Overall Vehicle Size | 31.6" w x 41.4" h |
| Rake / Trail | 28° / 4.4" |
| Bed Box Dimensions | 27.5 x 43.1 x 11.6 in (69.8 x 109 x 29.5 cm) |
| Lean Angle (Left) | 33 |
| Lean Angle (Right) | 33 |
| Hitch Type | Standard 2 in (5.08 cm) Receiver |
| Hitch Capacity | 1,500 lb (680 kg) |
| Cargo System | Lock & Ride |
| Payload Capacity | 499 lbs (1,100 kg) |
| Fuel Capacity | 5.28 gal (20 L) |
| Rack Capacity (Front) | 120 lb (54.4 kg |
| Rack Capacity (Rear) | 240 lb (109 kg) |
| Cargo Capacity | 187 lbs (412 kg) |
| Storage Capacity | 1.85 gal (7 L) |
| Towing Capacity | 830 lbs (1,830 kg) |
| Seating Capacity | 0 |
| Box Capacity | 600 lb (272 kg) Rear Dumping Box |
| Rack Capacity | Front: 120 lb (54.4 kg) / Rear: 240 lb (109 kg) |
| Bed Capacity | 299 pounds |
| Dry Weight | 1,023 lbs (465 kg) |
| Gauges | Speedometer, Tachometer, Odometer, Fuel Gauge, Compass, Ambient Temperature, Gear Indicator |
| Magneto | 1700-W |
| Audio System | Upgraded PowerBand 2.0 Audio package Includes: 2 - 100 watt fairing speakers, 2 - 100 watt saddlebag speakers. 2- 100 watt trunk speakers. 600 watts total. |
| Features | Main functions: Speedometer, tachometer, odometer, trips, distance to empty, engine lights, fuel gauge, clock, ECO mode and Rally mode |
| Lighting | LED Headlight, LED Tail/Brake/Turn Signals |
| Instrumentation | 4.5 in. (11,4 cm) digital display |
| Steering | Tri-Mode Dynamic Power Steering (DPS) |
| Cage Type | High strength (Dual phase) steel tubing and stampings |
| Warranty | Factory: 1-year BRP limited warranty with 1-year roadside assistance | Extended Service Terms: B.E.S.T. terms available from 12 to 36 months with roadside assistance |
| Handlebars | Aluminium, tapered 28/22 mm |
