Transmission | pDrive primary and Quick Response System X (QRS-X) CVT with high airflow, L / H / N / R / P |
Gearbox | 6-speed |
Clutch | Wet multi-disc, manual. Assist and Slipper. |
Chain Type | 2.2 : 1 |
Gear Ratios 1st | 9.403 : 1 |
Gear Ratios 2nd | 6.411 : 1 |
Gear Ratios 3rd | 4.763 : 1 |
Gear Ratios 4th | 3.796 : 1 |
Gear Ratios 5th | 3.243 : 1 |
Gear Ratios 6th | 2.789 : 1 |
Transmission Type | Chain (final drive) |
Front Suspension | Double A-arm with sway bar |
Rear Suspension | 4-link Torsional Trailing-arm X (TTX) with sway bar |
Front Shocks | FOX 2.5 PODIUM RC2 Piggyback with bypass, dual-speed compression and rebound adjustments |
Rear Shocks | FOX 3.0 PODIUM RC2 with bypass, dual-speed compression and rebound adjustments |
Front Travel | 4.7 in (119 mm) |
Rear Travel | 5.1 in (130 mm) |
Front Braking System | Dual 262 mm disc brakes with hydraulic twin-piston calipers |
Rear Braking System | Dual 248 mm disc brakes with hydraulic twin-piston calipers |
Parking Brake | Park In-Transmission |
Front Wheel | Cast Black 19 in x 3.5 in |
Rear Wheel | Cast Black 16 in x 5 in |
Front Tire | XPS Trac Force 32 x 10 x 15 in. |
Rear Tire | XPS Trac Force 32 x 10 x 15 in. |
Wheels | 15 in. cast-aluminum beadlock |
Wheelbase | 102 in (2,591 mm) |
Seat Height | 30.9 in |
Ground Clearance | 16 in (406 mm) |
Overall Vehicle Size | 28.7" w x 78.5" l x 44.1" h |
Rake / Trail | 29° / 5.2" |
Bed Box Dimensions | 36.75 x 54 x 11.5 in (93.3 x 137 x 29 cm) |
Lean Angle (Left) | 28.5 |
Lean Angle (Right) | 28.5 |
Cargo Capacity | 280 lbs (617 kg) |
Storage Capacity | 2.5 gal (9.4 L) |
Towing Capacity | 830 lbs (1,830 kg) |
Fuel Capacity | 10.5 gal (40 L) |
Seating Capacity | 2 |
Bed Capacity | 299 pounds |
Rack Capacity | 200 lb (91 kg) with LinQ quick-attach |
Rack Capacity (Front) | 0 lb (0 kg) |
Rack Capacity (Rear) | 1,000 lb. (453.6 kg) |
Payload Capacity | 794 lbs (1,750 kg) |
Hitch Type | Standard 2 in (5 cm) Receiver |
Hitch Capacity | 2,500 lb (1,134 kg) |
Cargo System | Lock & Ride |
Box Capacity | 1000 lbs (454 kg) |
Dry Weight | 1,680 lbs (762 kg) |
Gauges | 7.6 in. wide digital display with keypad |
Magneto | 850-W |
Audio System | Upgraded PowerBand 2.0 Audio package Includes: 2 - 100 watt fairing speakers, 2 - 100 watt saddlebag speakers. 400 watts total. |
Features | Anti-Theft System: RF Digitally Encoded Security System (D.E.S.S.) with Start/Stop button |
Instrumentation | DC outlet (10-A) |
Warranty | Factory: 6-month BRP Limited warranty | Extended: B.E.S.T. term available up to 30 months |
Lighting | LED headlight, LED tail lights |
Steering | Power: High torque Tri-Mode Dynamic Power Steering (DPS) |
Cage Type | Dual-phase 980 steel |
Handlebars | Neken, aluminium 28/22 mm |
