Transmission | pDrive primary and Quick Response System X (QRS-X) CVT with high airflow, L / H / N / R / P |
Clutch | |
Gearbox | 6-speed |
Transmission Type | Chain (final drive) |
Chain Type | Shaft |
Gear Ratios 1st | 10.926 : 1 |
Gear Ratios 2nd | 7.427 : 1 |
Gear Ratios 3rd | 5.918 : 1 |
Gear Ratios 4th | 5.022 : 1 |
Gear Ratios 5th | 4.087 : 1 |
Gear Ratios 6th | 3.017:1 |
Front Suspension | Double A-arm with sway bar |
Rear Suspension | 4-link Torsional Trailing-arm X (TTX) with sway bar |
Front Travel | 10.6 in (268 mm) |
Rear Travel | 10 in (254 mm) |
Front Shocks | FOX 2.5 PODIUM RC2 Piggyback with bypass, dual-speed compression and rebound adjustments |
Rear Shocks | FOX 3.0 PODIUM RC2 with bypass, dual-speed compression and rebound adjustments |
Front Braking System | Dual 262 mm disc brakes with hydraulic twin-piston calipers |
Rear Braking System | Dual 248 mm disc brakes with hydraulic twin-piston calipers |
Parking Brake | Park In-Transmission |
Wheels | 15 in. cast-aluminum beadlock |
Front Tire | XPS Trac Force 32 x 10 x 15 in. |
Rear Tire | XPS Trac Force 32 x 10 x 15 in. |
Front Wheel | Cast 16 in x 3.5 in |
Rear Wheel | Cast 16 in x 3.5 in |
Overall Vehicle Size | 63" w x 152.2" l x 76.1" h |
Rake / Trail | 26° / 7" |
Wheelbase | 102 in (2,591 mm) |
Seat Height | 28.9 in |
Ground Clearance | 16 in (406 mm) |
Bed Box Dimensions | 36.5 x 54 x 11.5 in (93 x 137 x 29 cm) |
Lean Angle (Left) | 31 |
Lean Angle (Right) | 31 |
Fuel Capacity | 10.5 gal (40 L) |
Seating Capacity | 0 |
Cargo System | Lock & Ride |
Payload Capacity | 467 lbs (1,030 kg) |
Box Capacity | 800 lb (363 kg); California 600 lb (272.2 kg) |
Hitch Type | 2 in. hitch receiver |
Cargo Capacity | 272 lbs (600 kg) |
Storage Capacity | 2.5 gal (9.4 L) |
Towing Capacity | 907 lbs (2,000 kg) |
Hitch Capacity | 1,500 lb (680 kg) |
Rack Capacity (Front) | 33 pounds |
Rack Capacity (Rear) | 800 lb. (363 kg) |
Bed Capacity | 900 pounds |
Rack Capacity | 200 lb (91 kg) with LinQ quick-attach |
Dry Weight | 1,680 lbs (762 kg) |
Gauges | 7.6 in. wide digital display with keypad |
Audio System | Upgraded PowerBand 2.0 Audio package Includes: 2 - 100 watt fairing speakers, 2 - 100 watt saddlebag speakers. 400 watts total. |
Magneto | 850-W |
Warranty | Factory: 6-month BRP Limited warranty | Extended: B.E.S.T. term available up to 30 months |
Steering | Power: High torque Tri-Mode Dynamic Power Steering (DPS) |
Features | Anti-Theft System: RF Digitally Encoded Security System (D.E.S.S.) with Start/Stop button |
Lighting | LED headlight, LED tail lights |
Instrumentation | DC outlet (10-A) |
Cage Type | Dual-phase 980 steel |
Handlebars | Ergonomy and controls sized for 6 years old and up |
