Transmission | pDrive primary and Quick Response System X (QRS-X) CVT with high airflow, L / H / N / R / P |
Transmission Type | Belt |
Clutch | Multi-plate with diaphragm spring in oil bath |
Gearbox | 6-speed |
Chain Type | O-ring-sealed chain; 15T/40T |
Gear Ratios 1st | 2.769:1 |
Gear Ratios 2nd | 1.882:1 |
Gear Ratios 3rd | 1.500:1 |
Gear Ratios 4th | 1.273:1 |
Gear Ratios 5th | 1.125:1 |
Gear Ratios 6th | 0.966:1 |
Front Suspension | Double A-arm with sway bar |
Rear Suspension | 4-link Torsional Trailing-arm X (TTX) with sway bar |
Front Travel | 10.6 in (268 mm) |
Rear Travel | 10 in (254 mm) |
Front Shocks | FOX 2.5 PODIUM RC2 Piggyback with dual-speed compression and rebound adjustments |
Rear Shocks | FOX 2.5 PODIUM RC2 Piggyback with dual-speed compression, rebound adjustments and bottom-out control |
Front Braking System | Dual 262 mm disc brakes with hydraulic twin-piston calipers |
Rear Braking System | Dual 248 mm disc brakes with hydraulic twin-piston calipers |
Parking Brake | Electrically actuated |
Front Tire | XPS Trac Force 30 x 10 x 14 in. |
Rear Tire | XPS Trac Force 30 x 10 x 14 in. |
Wheels | 14 in. cast-aluminum |
Front Wheel | Rim: 6-spoke, Deep black, 15 x 5 in. (381 x 127 mm) |
Rear Wheel | Rim: 6-spoke, 15 x 7 in. (381 mm x 178 mm) |
Overall Vehicle Size | 95.7" length |
Seat Height | 29.7 in (755 mm) |
Rake / Trail | 28° / 4.3" |
Wheelbase | 102 in (2,591 mm) |
Ground Clearance | 14 in (356 mm) |
Lean Angle (Left) | 33 |
Lean Angle (Right) | 33 |
Bed Box Dimensions | 26 x 17.7 x 11.5 in (66 x 45 x 29.2 cm) |
Fuel Capacity | 10.5 gal (40 L) |
Seating Capacity | 0 |
Bed Capacity | 1000 pounds for 49-state models |
Storage Capacity | 2.5 gal (9.4 L) |
Towing Capacity | 182 lbs (400 kg) |
Rack Capacity | 200 lb (91 kg) with LinQ quick-attach |
Hitch Capacity | 2,500 lb (1,134 kg) |
Cargo System | Lock & Ride Fold Flat Rear Storage, convertible rear seat storage with integrated tie down points, 27.7 x 52.8 x 19.5 in (70.4 x 134.1 x 49.53 cm) |
Payload Capacity | 408 lbs (900 kg) |
Box Capacity | 300 lb (136 kg) |
Cargo Capacity | 224 lbs (494 kg) |
Hitch Type | Standard 1.25 in (3.2 cm) Receiver |
Rack Capacity (Front) | 33 pounds |
Rack Capacity (Rear) | 66 pounds |
Dry Weight | 1,554 lbs (705 kg) |
Gauges | 7.6 in. wide digital display with keypad |
Magneto | 850-W |
Audio System | Includes 2 Standard 50 watt fairing speakers, 100 watts total. |
Warranty | Factory: 6-month BRP Limited warranty | Extended: B.E.S.T. term available up to 30 months |
Features | Anti-Theft System: RF Digitally Encoded Security System (D.E.S.S.) with Start/Stop button |
Lighting | LED headlight, LED signature, LED tail lights |
Steering | Power: High torque Tri-Mode Dynamic Power Steering (DPS) |
Instrumentation | DC outlet (10-A) |
Cage Type | Dual-phase 980 steel |
Handlebars | Aluminum |
