Transmission | pDrive primary and Quick Response System X (QRS-X) CVT with high airflow, L / H / N / R / P |
Transmission Type | Five-speed manual with reverse |
Clutch | Wet multi-disc, manual. Assist and Slipper. |
Gearbox | 6-speed |
Chain Type | O-ring-sealed chain; 14T/36T |
Gear Ratios 2nd | 1.882 : 1 |
Gear Ratios 1st | 2.769 : 1 |
Gear Ratios 3rd | 1.500 : 1 |
Gear Ratios 4th | 1.273 : 1 |
Gear Ratios 5th | 1.125 : 1 |
Gear Ratios 6th | 0.966 : 1 |
Front Suspension | Double A-arm with sway bar |
Rear Suspension | 4-link Torsional Trailing-arm X (TTX) with sway bar |
Front Travel | 10.6 in (268 mm) |
Rear Travel | 10 in (254 mm) |
Front Shocks | SHOWA HPG piggyback 2.5 (dual-speed Compression, Dual-rate spring) |
Rear Shocks | SHOWA HPG piggyback 2.5 (dual-speed Compression, Dual-rate spring) |
Front Braking System | Dual 262 mm disc brakes with hydraulic twin-piston calipers |
Rear Braking System | Dual 248 mm disc brakes with hydraulic twin-piston calipers |
Parking Brake | Park In-Transmission |
Wheels | 14 in. cast-aluminum |
Front Tire | XPS Trac Force 30 x 10 x 14 in. |
Rear Tire | XPS Trac Force 30 x 10 x 14 in. |
Front Wheel | 10-spoke, Platinum silver, 16 x 4.5 in. (406 x 114 mm) |
Rear Wheel | 10-spoke, Platinum Silver, 16 x 6.5 in. (406 x 165 mm) |
Wheelbase | 102 in (2,591 mm) |
Ground Clearance | 16 in (406 mm) |
Bed Box Dimensions | 36.2 x 47.25 x 13.38 in (92 x 120 x 34 cm) |
Overall Vehicle Size | 47.4" w x 86" l x 48.7" h |
Seat Height | 36.3 in |
Rake / Trail | 28° / 4.3" |
Lean Angle (Left) | 33 |
Lean Angle (Right) | 33 |
Cargo System | Lock & Ride MAX |
Payload Capacity | 680 lbs (1,500 kg) |
Fuel Capacity | 10.5 gal (40 L) |
Box Capacity | 600 lb (272 kg) |
Cargo Capacity | 454 lbs (1,000 kg) |
Storage Capacity | 2.5 gal (9.4 L) |
Hitch Type | 2 in. hitch receiver |
Hitch Capacity | 2,000 lb (907 kg) |
Rack Capacity (Front) | 120 lb (55 kg) |
Rack Capacity (Rear) | 240 lb (110 kg) |
Seating Capacity | 0 |
Bed Capacity | 299 pounds |
Towing Capacity | 1,134 lbs (2,500 kg) |
Rack Capacity | 200 lb (91 kg) with LinQ quick-attach |
Dry Weight | 1,673 lbs (759 kg) |
Gauges | 4.5 in. digital display with keypad |
Magneto | 850-W |
Audio System | Includes 4 Standard 50 watt speakers. 2 in the fairing, 2 in the trunk. 200 watts total. |
Features | Anti-Theft System: RF Digitally Encoded Security System (D.E.S.S.) with Start/Stop button |
Lighting | LED headlight, LED tail lights |
Instrumentation | DC outlet (10-A) |
Warranty | Factory: 6-month BRP Limited warranty | Extended: B.E.S.T. term available up to 30 months |
Steering | Power: High torque Tri-Mode Dynamic Power Steering (DPS) |
Handlebars | Neken, aluminium 28/22 mm |
Cage Type | Dual-phase 980 steel |
