Transmission | pDrive primary and Quick Response System X (QRS-X) CVT with high airflow, L / H / N / R / P |
Transmission Type | Chain (final drive) |
Clutch | Wet, Multi-Plate |
Gearbox | 5-speed |
Chain Type | 2.2 : 1 |
Gear Ratios 1st | 9.403 : 1 |
Gear Ratios 2nd | 6.411 : 1 |
Gear Ratios 3rd | 4.763 : 1 |
Gear Ratios 4th | 3.796 : 1 |
Gear Ratios 5th | 3.243 : 1 |
Gear Ratios 6th | 2.789 : 1 |
Front Suspension | Double A-arm with sway bar |
Rear Suspension | 4-link Torsional Trailing-arm X (TTX) with sway bar |
Front Shocks | SHOWA HPG piggyback 2.5 (dual-speed Compression, Dual-rate spring) |
Rear Shocks | SHOWA HPG piggyback 2.5 (dual-speed Compression, Dual-rate spring) |
Front Travel | 16 in (406 mm) |
Rear Travel | 18 in (457 mm) |
Front Braking System | Dual 262 mm disc brakes with hydraulic twin-piston calipers |
Rear Braking System | Dual 248 mm disc brakes with hydraulic twin-piston calipers |
Parking Brake | Park In-Transmission |
Front Tire | XPS Trac Force 30 x 10 x 14 in. |
Rear Tire | XPS Trac Force 30 x 10 x 14 in. |
Wheels | 14 in. cast-aluminum |
Front Wheel | Cast 16 in x 3.5 in |
Rear Wheel | Cast 16 in x 5 in |
Wheelbase | 102 in (2,591 mm) |
Ground Clearance | 14 in (356 mm) |
Bed Box Dimensions | 28 x 22 x 7 in (72.0 x 57.0 x 17.8 cm) |
Overall Vehicle Size | 39.4" w x 101.2" l x 54.7" h |
Seat Height | 26 in (660 mm) |
Rake / Trail | 25° / 5.9" |
Lean Angle (Left) | 31 |
Lean Angle (Right) | 31 |
Hitch Capacity | 2,000 lb (907 kg) |
Cargo System | Lock & Ride |
Payload Capacity | 336 lbs (740 kg) |
Fuel Capacity | 10.5 gal (40 L) |
Box Capacity | 300 lb (136 kg) |
Seating Capacity | 2 |
Bed Capacity | 299 pounds |
Storage Capacity | 2.5 gal (9.4 L) |
Rack Capacity | 200 lb (91 kg) with LinQ quick-attach |
Dry Weight | 1,546 lbs (701 kg) |
Gauges | 4.5 in. digital display with keypad |
Magneto | 650-W |
Features | Anti-Theft System: RF Digitally Encoded Security System (D.E.S.S.) with Start/Stop button |
Lighting | LED headlight, LED tail lights |
Instrumentation | DC outlet (10-A) |
Warranty | Factory: 6-month BRP Limited warranty | Extended: B.E.S.T. term available up to 30 months |
Steering | Power: High torque Tri-Mode Dynamic Power Steering (DPS) |
Cage Type | Dual-phase 980 steel |
