Transmission | pDrive primary CVT with engine braking and electronic drive belt protection L / H / N / R / P |
Transmission Type | Chain (final drive) |
Clutch | Wet multiplate with coil springs |
Gearbox | 6-speed |
Chain Type | #520 O-ring-sealed chain; 15T/45T |
Gear Ratios 2nd | 6.411 : 1 |
Gear Ratios 1st | 9.403 : 1 |
Gear Ratios 3rd | 4.763 : 1 |
Gear Ratios 4th | 3.796 : 1 |
Gear Ratios 5th | 3.243 : 1 |
Gear Ratios 6th | 2.789 : 1 |
Front Suspension | Double A-arm with sway bar |
Rear Suspension | 13 in. (33 cm) |
Front Shocks | Twin tube gas charged shocks |
Rear Shocks | Twin tube gas charged shocks |
Front Travel | 11.6 in (295 mm) |
Rear Travel | 14 in (356 mm) |
Front Braking System | Dual 220 mm disc brakes with hydraulic twin-piston calipers |
Rear Braking System | Dual 220 mm disc brakes with hydraulic twin-piston calipers |
Parking Brake | Park In-Transmission |
Wheels | 14 in. cast aluminum | Steering: Adjustable tilt steering |
Front Tire | XPS Trail King 28 x 9/11 x 14 in. |
Rear Tire | XPS Trail King 28 x 9/11 x 14 in. |
Front Wheel | Wire Spoke 16 in x 3 in |
Rear Wheel | Wire Spoke 16 in x 5 in |
Seat Height | 38.6 in (980 mm) |
Overall Vehicle Size | 64" w x 152.6" l x 78.1" h |
Rake / Trail | 27° / 4" |
Wheelbase | 90.6 in (2,301 mm) |
Ground Clearance | 13 in (330 mm) |
Bed Box Dimensions | 43.4 x 56 x 13.4 in (110.2 x 142.2 x 34 cm) |
Lean Angle (Left) | 28.5 |
Lean Angle (Right) | 28.5 |
Seating Capacity | 0 |
Fuel Capacity | 10 gal (38 L) |
Towing Capacity | 907 lbs (2,000 kg) |
Bed Capacity | 1,500 lbs. (680 kg) |
Hitch Type | 2 in. hitch receiver |
Hitch Capacity | 3,500 lbs. (1588 kg) |
Cargo System | Lock & Ride MAX |
Payload Capacity | 467 lbs (1,030 kg) |
Box Capacity | 1,500 lbs. (680 kg) |
Cargo Capacity | 272 lbs (600 kg) |
Storage Capacity | 7.3 gal (27.6 L) |
Rack Capacity | Front: 120 lb (54.4 kg) / Rear: 240 lb (109 kg) |
Rack Capacity (Front) | 90 lb (40.8 kg) |
Rack Capacity (Rear) | 1,000 lb. (453.6 kg) |
Dry Weight | 1,575 lbs (714 kg) |
Gauges | 7.6 in. digital display with keypad |
Magneto | 650-W |
Audio System | Upgraded PowerBand 2.0 Audio package Includes: 2 - 100 watt fairing speakers, 2 - 100 watt saddlebag speakers. 2- 100 watt trunk speakers. 600 watts total. |
Warranty | Factory: 6-month BRP Limited warranty | Extended: B.E.S.T. term available up to 30 months |
Steering | Power: Dynamic Power Steering (DPS) |
Features | Anti-Theft System: RF Digitally Encoded Security System (D.E.S.S.) with Start / Stop button |
Lighting | Front lighting output 110-W, LED signature, LED tail lights |
Instrumentation | DC outlet (10-A) |
Handlebars | Aluminum |
Cage Type | Profiled cage, ROPS approved |
Headlight Type | LED |
