Transmission | Gen 2 Automatic PVT H/L/N/R/P; Shaft |
Chain Type | #520 Chain; 16T/45T |
Clutch | Wet, Multi-Plate |
Gear Ratios 1st | 2.769:1 |
Gear Ratios 2nd | 1.882:1 |
Gear Ratios 3rd | 1.500:1 |
Gear Ratios 4th | 1.273:1 |
Gear Ratios 5th | 1.125:1 |
Gear Ratios 6th | 0.966:1 |
Gearbox | 6-speed |
Transmission Type | Chain (final drive) |
Front Suspension | Dual A-Arm |
Rear Suspension | Dual A-Arm IRS |
Front Travel | 5.1 in (130 mm) |
Rear Travel | 5.1 in (130 mm) |
Front Shocks | Twin tube |
Rear Shocks | Twin tube |
Front Braking System | 4-Wheel Hydraulic Disc with Dual-Bore Front and Rear Calipers |
Rear Braking System | 4-Wheel Hydraulic Disc with Dual-Bore Front and Rear Calipers |
Parking Brake | Park In-Transmission |
Front Wheel | Cast 8-Spoke 16" x 3.5" |
Rear Wheel | Cast 8-Spoke 16" x 3.5" |
Front Tire | 25 x 10-12; Carlisle 489 |
Rear Tire | 25 x 11-12; Carlisle 489 |
Wheels | Stamped Steel |
Overall Vehicle Size | 30.8" w x 42.7" h |
Rake / Trail | 25° / 3.9" |
Wheelbase | 81 in (2,060 mm) |
Seat Height | 31.3 in (795 mm) |
Ground Clearance | 12 in (305 mm) |
Lean Angle (Left) | 31 |
Lean Angle (Right) | 31 |
Bed Box Dimensions | 36.5 x 54 x 11.5 in (93 x 137 x 29 cm) |
Seating Capacity | 0 |
Fuel Capacity | 11.35 gal (43 L) |
Hitch Type | Standard 2 in (5 cm) Receiver |
Cargo Capacity | 199 lbs (439 kg) |
Payload Capacity | 680 lbs (1,500 kg) |
Storage Capacity | 9 gal (34 L) |
Towing Capacity | 830 lbs (1,830 kg) |
Rack Capacity (Front) | 120 lb (54.4 kg) |
Rack Capacity (Rear) | 240 lb (109 kg) |
Hitch Capacity | 2,500 lb (1,134 kg) |
Cargo System | Lock & Ride |
Box Capacity | 1000 lbs (454 kg) |
Bed Capacity | 299 pounds |
Rack Capacity | Front: 120 lb (54.4 kg) / Rear: 240 lb (109 kg) |
Dry Weight | 1,437 lbs (652 kg) |
Gauges | Black Smoke |
Magneto | 850 W |
Audio System | Includes 2 Standard 50 watt fairing speakers, 100 watts total. |
Features | Water Fording Height: Equal to the Floorboards | Other Standard: Single Latch Cab Nets, Polaris Pulse Electrical System (3 position), 12V Accessory Outlet, Battery Trickle-Charging Outlet |
Lighting | Halogen Headlights, 55W Low Beam, 60W High Beam, Dual LED Tail Lights |
Warranty | Duration: Transferable, one year included, unlimited-mileage limited warranty |
Steering | Tilt: Standard |
Handlebars | Aluminum |
Cage Type | Profiled cage, ROPS approved |
Instrumentation | 4" LCD Rider Information Center: User Selectable Blue/Red Backlighting & Brightness, Programmable Service Intervals, Speedometer, Tachometer, Odometer, Tripmeter, Clock, Hour Meter, Gear Indicator, Fuel Gauge, Coolant Temperature, Voltmeter, Service Indicator and Codes, Seat Belt Reminder, DC Outlet |
