Transmission | PRO-TORQ CVT with Quick Response System (QRS), high-airflow ventilation and Electronic Drive Bel |
Transmission Type | Chain (final drive) |
Clutch | Multiplate wet clutch; with assist and slipper |
Gearbox | 6-speed |
Chain Type | #428 Chain; 14T/38T |
Gear Ratios 2nd | 6.411 : 1 |
Gear Ratios 1st | 9.403 : 1 |
Gear Ratios 3rd | 4.763 : 1 |
Gear Ratios 4th | 3.796 : 1 |
Gear Ratios 5th | 3.243 : 1 |
Gear Ratios 6th | 2.789 : 1 |
Front Suspension | Double A-arm |
Rear Suspension | TTA with external sway bar |
Front Shocks | Twin tube gas-charged shocks |
Rear Shocks | Twin tube gas-charged shocks |
Front Travel | 5.1 in (130 mm) |
Rear Travel | 5.1 in (130 mm) |
Front Braking System | Dual 220 mm disc brakes with hydraulic twin-piston calipers |
Rear Braking System | Dual 220 mm disc brakes with hydraulic single-piston calipers |
Parking Brake | Park In-Transmission |
Wheels | 14 in. cast aluminum | Steering: Adjustable tilt steering |
Front Tire | XPS Trail Force 27 x 9 / 11 x 14 in. |
Rear Tire | XPS Trail Force 27 x 9 / 11 x 14 in. |
Front Wheel | Highlight Machine Tour 17 in x 3.5 in |
Rear Wheel | Highlight Machine Tour 16 in x 5 in |
Seat Height | 32.9 in (836 mm) |
Overall Vehicle Size | 63" w x 76.3" h |
Rake / Trail | 23.7° / 4" |
Wheelbase | 83 in (2,115 mm) |
Ground Clearance | 11 in (280 mm) |
Bed Box Dimensions | 36.75 x 54.25 x 12.5 in (93 x 138 x 32 cm) |
Lean Angle (Left) | 31 |
Lean Angle (Right) | 31 |
Seating Capacity | 0 |
Fuel Capacity | 10.6 gal (40 L) |
Towing Capacity | 1,134 lbs (2,500 kg) |
Bed Capacity | 600 lb (272 kg) Rear Dumping Box |
Hitch Type | 2 in. hitch receiver |
Hitch Capacity | 2,500 lb (1,134 kg) |
Cargo System | Lock & Ride |
Payload Capacity | 680 lbs (1,500 kg) |
Box Capacity | 1000 lbs (454 kg) |
Cargo Capacity | 454 lbs (1,000 kg) |
Storage Capacity | 16.2 gal (61.3 L) |
Rack Capacity | 150 lb (68 kg) with LinQ quick-attach |
Rack Capacity (Front) | 120 lb (54.4 kg) |
Rack Capacity (Rear) | 800 lb. (363 kg) |
Dry Weight | 1,577 lbs (717 kg) |
Gauges | 4.5 in. wide digital display |
Magneto | 650 W |
Audio System | Includes 2 Standard 50 watt fairing speakers, 100 watts total. |
Warranty | Factory: 1 year BRP limited warranty | Extended: B.E.S.T. term available up to 30 months |
Steering | Power: Dynamic Power Steering (DPS) |
Features | Anti-Theft System: RF Digitally Encoded Security System (D.E.S.S.) with Start/Stop button |
Lighting | Front lighting output 140 W LED tail lights |
Instrumentation | DC outlet (10 A) USB port (10 A) x 2 |
Handlebars | Aluminum |
Cage Type | Profiled cage, ROPS approved |
Headlight Type | LED |
