Transmission | PRO-TORQ Transmission with Quick Response System (QRS), Electronic Drive Belt Protection, lower |
Transmission Type | Chain |
Clutch | Wet multi-plate |
Gearbox | 5-speed |
Chain Type | 520 X-Ring |
Gear Ratios 1st | 2.769 : 1 |
Gear Ratios 2nd | 46:14 |
Gear Ratios 3rd | 1.500 : 1 |
Gear Ratios 4th | 1.273 : 1 |
Gear Ratios 5th | 1.125 : 1 |
Gear Ratios 6th | 0.966 : 1 |
Front Suspension | Arched double A-arm with sway bar |
Rear Suspension | Arched TTA with external sway bar |
Front Travel | 4.3 in (109 mm) |
Rear Travel | 3.8 in (97 mm) |
Front Shocks | Twin tube gas-charged shocks |
Rear Shocks | Twin tube gas-charged shocks |
Front Braking System | Dual 220 mm disc brakes with hydraulic twin-piston calipers |
Rear Braking System | Dual 220 mm disc brakes with hydraulic single-piston calipers |
Parking Brake | Park In-Transmission |
Wheels | 14 in. cast aluminum | Steering: Adjustable tilt steering |
Front Tire | XPS Swamp Force 30 x 9 / 11 x 14 in |
Rear Tire | XPS Swamp Force 30 x 9 / 11 x 14 in |
Front Wheel | Wire 40-Spoke 16" x 3.5" |
Rear Wheel | Wire 40-Spoke 16" x 3.5" |
Overall Vehicle Size | 34.4" w x 90.9" l x 48.4" h |
Seat Height | 36.8 in |
Wheelbase | 83 in (2,115 mm) |
Ground Clearance | 15 in (381 mm) |
Rake / Trail | 25.4° / 2" |
Lean Angle (Left) | 33 |
Lean Angle (Right) | 33 |
Bed Box Dimensions | 36.75 x 54.25 x 12.5 in (93 x 138 x 32 cm) |
Seating Capacity | 0 |
Fuel Capacity | 10.6 gal (40 L) |
Hitch Type | 2 in. hitch receiver |
Hitch Capacity | 2,500 lb (1,134 kg) |
Cargo System | Lock & Ride |
Payload Capacity | 680 lbs (1,500 kg) |
Rack Capacity (Front) | 120 lb (54.4 kg) |
Rack Capacity (Rear) | 240 lb (109 kg) |
Cargo Capacity | 454 lbs (1,000 kg) |
Storage Capacity | 16.2 gal (61.3 L) |
Box Capacity | 1000 lbs (454 kg) |
Towing Capacity | 1,134 lbs (2,500 kg) |
Bed Capacity | 299 pounds |
Rack Capacity | Front: 120 lb (54.4 kg) / Rear: 240 lb (109 kg) |
Dry Weight | 1,811 lbs (821 kg) |
Gauges | 7.6 in. wide digital display with keypad |
Audio System | Includes 2 Standard 50 watt fairing speakers, 100 watts total. |
Magneto | 650 W |
Warranty | Factory: 1 year BRP limited warranty | Extended: B.E.S.T. term available up to 30 months |
Features | Anti-Theft System: Mechanical key |
Instrumentation | DC outlet (10 A), USB port (10 A) x 2 |
Lighting | Front lighting output 140 W, LED signature, LED tail lights |
Steering | Power: Dynamic Power Steering (DPS) |
Handlebars | Aluminum |
Cage Type | Profiled cage, ROPS approved |
