Drivetrain
| Transmission | PRO-TORQ Transmission with Quick Response System (QRS), Electronic Drive Belt Protection, lower |
| Transmission Type | Chain |
| Clutch | Wet clutch |
| Gearbox | 6-speed |
| Chain Type | 2.2 : 1 |
| Gear Ratios 1st | 9.403 : 1 |
| Gear Ratios 2nd | 6.411 : 1 |
| Gear Ratios 3rd | 4.763 : 1 |
| Gear Ratios 4th | 3.796 : 1 |
| Gear Ratios 5th | 3.243 : 1 |
| Gear Ratios 6th | 2.789 : 1 |
Suspension
| Front Suspension | Arched double A-arm with sway bar |
| Rear Suspension | Arched TTA with external sway bar |
| Front Travel | 4.7 in (119 mm) |
| Rear Travel | 4.5 in (114 mm) |
| Front Shocks | Twin tube gas charged shocks |
| Rear Shocks | Twin tube gas charged shocks |
Brakes
| Front Braking System | Dual 220 mm disc brakes with hydraulic twin-piston calipers |
| Rear Braking System | Dual 220 mm disc brakes with hydraulic twin-piston calipers |
| Parking Brake | Park In-Transmission |
Tires
| Wheels | 14 in. cast-aluminum | Steering: Adjustable tilt steering |
| Front Tire | XPS Swamp Force 30 x 9/11 x 14 in. |
| Rear Tire | XPS Swamp Force 30 x 9/11 x 14 in. |
| Front Wheel | Highlight Machine Tour 17 in x 3.5 in |
| Rear Wheel | Highlight Machine Tour 16 in x 5 in |
Dimensions
| Overall Vehicle Size | 39.4" w x 98.7" l x 54.5" h |
| Seat Height | 25.6 in (650 mm) |
| Wheelbase | 115.5 in (2,940 mm) |
| Ground Clearance | 15 in (381 mm) |
| Rake / Trail | 25° / 6" |
| Lean Angle (Left) | 31 |
| Lean Angle (Right) | 31 |
| Bed Box Dimensions | 36.75 x 54.25 x 12.5 in (93 x 138 x 32 cm) |
Capacities
| Hitch Type | 2 in. hitch receiver |
| Hitch Capacity | 2,500 lb (1,134 kg) |
| Cargo System | Lock & Ride |
| Payload Capacity | 646 lbs (1,425 kg) |
| Fuel Capacity | 10.6 gal (40 L) |
| Rack Capacity (Front) | 120 lb (54.4 kg) |
| Rack Capacity (Rear) | 240 lb (109 kg) |
| Seating Capacity | 0 |
| Box Capacity | 1000 lbs (454 kg) |
| Storage Capacity | 16.9 gal (63.9 L) |
| Towing Capacity | 1,134 lbs (2,500 kg) |
| Bed Capacity | 299 pounds |
| Cargo Capacity | 454 lbs (1,000 kg) |
| Rack Capacity | Front: 120 lb (54.4 kg) / Rear: 240 lb (109 kg) |
Weights
| Dry Weight | 2,174 lbs (986 kg) |
Electronics
| Gauges | 7.6 in. wide digital display with keypad |
| Audio System | Includes 4 Standard 50 watt speakers. 2 in the fairing, 2 in the trunk. 200 watts total. |
| Magneto | 650 W |
Lights & Safety
| Warranty | Factory: 1-year BRP Limited warranty | Extended: B.E.S.T. term available up to 30 months |
| Features | Anti-Theft System: |
| Lighting | Front lighting output 140-W, LED signature, LED tail lights |
| Instrumentation | DC outlet (10-A), USB Port (10-A) x 4 |
| Steering | Power: Dynamic Power Steering (DPS) |
| Cage Type | Profiled cage ROPS approved |
| Handlebars | Neken, aluminium 28/22 mm |
Frequently asked questions about 2025 Can-Am Defender MAX X mr with Half-Doors HD10 Wildland Camo
What type of fuel does a 2025 Can-Am Defender MAX X mr with Half-Doors HD10 Wildland Camo use?
A 2025 Can-Am Defender MAX X mr with Half-Doors HD10 Wildland Camo uses Gasoline.
What is the 2025 Can-Am Defender MAX X mr with Half-Doors HD10 Wildland Camo fuel capacity?
A 2025 Can-Am Defender MAX X mr with Half-Doors HD10 Wildland Camo has the fuel capacity of 11 gallons.
How much horsepower does a 2025 Can-Am Defender MAX X mr with Half-Doors HD10 Wildland Camo have?
A 2025 Can-Am Defender MAX X mr with Half-Doors HD10 Wildland Camo has 82 horsepower.
How is the 2025 Can-Am Defender MAX X mr with Half-Doors HD10 Wildland Camo cooled?
The 2025 Can-Am Defender MAX X mr with Half-Doors HD10 Wildland Camo is cooled by Liquid-cooled with strategically positioned engine air intake.
What type of fuel system does the 2025 Can-Am Defender MAX X mr with Half-Doors HD10 Wildland Camo have?
The 2025 Can-Am Defender MAX X mr with Half-Doors HD10 Wildland Camo is equipped with a Intelligent Throttle Control (iTC) with Electronic Fuel Injection (EFI) fuel system.
What type of front brakes does the 2025 Can-Am Defender MAX X mr with Half-Doors HD10 Wildland Camo have?
The 2025 Can-Am Defender MAX X mr with Half-Doors HD10 Wildland Camo is equipped with Dual 220 mm disc brakes with hydraulic twin-piston calipers front brakes.
What type of rear brakes does the 2025 Can-Am Defender MAX X mr with Half-Doors HD10 Wildland Camo have?
The 2025 Can-Am Defender MAX X mr with Half-Doors HD10 Wildland Camo is equipped with Dual 220 mm disc brakes with hydraulic twin-piston calipers rear brakes.
