Transmission | pDrive primary CVT, L / H / N / R / P |
Clutch | Wet multi-disc, manual. Assist and Slipper. |
Gearbox | 6-speed |
Chain Type | 2.357 : 1 |
Gear Ratios 2nd | 7.427 : 1 |
Transmission Type | Chain (final drive) |
Gear Ratios 1st | 10.926 : 1 |
Gear Ratios 3rd | 5.918 : 1 |
Gear Ratios 4th | 5.022: 1 |
Gear Ratios 5th | 4.439 : 1 |
Gear Ratios 6th | 4.087 : 1 |
Front Suspension | Arched Double A-arm |
Rear Suspension | Arched Double A-arm |
Front Travel | 7.9 in (201 mm) |
Rear Travel | 9.1 in (231 mm) |
Front Shocks | Twin tube |
Rear Shocks | Twin tube |
Front Braking System | Dual 214 mm disc brakes with hydraulic twin-piston calipers |
Rear Braking System | Single 214 mm disc brake with hydraulic twin-piston caliper |
Parking Brake | Electrically actuated |
Wheels | 14 in. Aluminum |
Front Tire | XPS Trail King 2 - 26 x 8/10 x 14 |
Rear Tire | XPS Trail King 2 - 26 x 8/10 x 14 |
Front Wheel | Rims: 10-spoke, Deep Black, 15 x 5 in. (381 x 127 mm) on F3 Limited Monolith Black Satin & Petrol Metallic |
Rear Wheel | Rims: 6-spoke, 15 x 7 in. (381 mm x 178 mm) |
Rake / Trail | 26° / 7" |
Wheelbase | 52.8 in (1,342 mm) |
Seat Height | 37.8 in (960 mm) |
Ground Clearance | 11.5 in (292 mm) |
Overall Vehicle Size | 64" w x 80.9" h |
Lean Angle (Left) | 31 |
Lean Angle (Right) | 31 |
Bed Box Dimensions | 26 x 17.7 x 11.5 in (66 x 45 x 29.2 cm) |
Fuel Capacity | 5.1 gal (19.5 L) |
Towing Capacity | 830 lbs (1,830 kg) |
Bed Capacity | 1000 pounds |
Seating Capacity | 0 |
Cargo Capacity | 199 lbs (439 kg) |
Storage Capacity | 10.6 gal (40 L) |
Cargo System | Lock & Ride, 4 Gal (15 L) Front Dry Storage 2 Gal (8 L) Rear Storage |
Payload Capacity | 261 lbs (575 kg) |
Box Capacity | 300 lb (136 kg) |
Hitch Type | Standard 1.25 in (3.2 cm) Receiver |
Rack Capacity | 150 lb (68 kg) with LinQ quick-attach |
Rack Capacity (Front) | 120 lb (54.4 kg |
Rack Capacity (Rear) | 240 lb (109 kg) |
Hitch Capacity | 1,500 lb (680 kg) |
Dry Weight | 1,000 lbs (455 kg) |
Gauges | 7.6 in. wide digital display |
Magneto | 650 W |
Audio System | Includes 2 Standard 50 watt fairing speakers, 100 watts total. |
Warranty | Factory: 6-month BRP Limited warranty | Extended: B.E.S.T. term available up to 36 months |
Steering | Power: Tri-Mode Dynamic Power Steering (DPS) |
Handlebars | Aluminum |
Features | Anti-Theft System: RF Digitally Encoded Security System (D.E.S.S.) |
Lighting | LED headlights and tail lights |
Instrumentation | Phone storage & USB charger |
Cage Type | Profiled cage, ROPS approved |
