| Chain Type | Shaft |
| Clutch | Wet, Multi-Plate |
| Gear Ratios 1st | 2.769 : 1 |
| Gear Ratios 2nd | 1.882 : 1 |
| Gear Ratios 3rd | 1.500 : 1 |
| Gear Ratios 4th | 1.273 : 1 |
| Gear Ratios 5th | 1.125 : 1 |
| Gear Ratios 6th | 0.966 : 1 |
| Transmission | Gen 2 Automatic PVT H/L/N/R/P; Shaft |
| Gearbox | 6-speed |
| Front Suspension | Dual A-Arm |
| Rear Suspension | Dual A-Arm IRS |
| Front Shocks | Twin tube gas-charged shocks |
| Rear Shocks | Twin tube gas-charged shocks |
| Front Travel | 5.1 in (130 mm) |
| Rear Travel | 5.2 in (132 mm) |
| Front Braking System | 4-Wheel Hydraulic Disc with Dual-Bore Front Calipers |
| Rear Braking System | 4-Wheel Hydraulic Disc with Dual-Bore Front Calipers |
| Parking Brake | Park In-Transmission |
| Front Wheel | Contrast Cut 16 in x 3.5 in |
| Rear Wheel | Contrast Cut 16 in x 3.5 in |
| Front Tire | 29 x 9-14; PRO ARMOR X-TERRAIN | Tire Ply Rating:8-Ply Rated |
| Rear Tire | 29 x 11-14; PRO ARMOR X-TERRAIN | Tire Ply Rating:8-Ply Rated |
| Wheels | Aluminum |
| Overall Vehicle Size | 62.8" w x 77.3" h |
| Rake / Trail | 32° / 3.6" |
| Wheelbase | 113 in (2,870 mm) |
| Seat Height | 26.7 in (678 mm) |
| Ground Clearance | 14 in (360 mm) |
| Lean Angle (Left) | 33 |
| Lean Angle (Right) | 33 |
| Bed Box Dimensions | 36.75 x 54.25 x 12.5 in (93 x 138 x 32 cm) |
| Fuel Capacity | 11.5 gal (43.5 L) |
| Towing Capacity | 1,134 lbs (2,500 kg) |
| Bed Capacity | 1000 pounds (49 states) |
| Hitch Type | Standard 2 in (5 cm) Receiver |
| Cargo Capacity | 454 lbs (1,000 kg) |
| Payload Capacity | 522 lbs (1,150 kg) |
| Storage Capacity | 16.2 gal (61.3 L) |
| Rack Capacity | 150 lb (68 kg) with LinQ quick-attach |
| Seating Capacity | 2 |
| Cargo System | Lock & Ride |
| Box Capacity | 1000 lbs (454 kg) |
| Rack Capacity (Front) | 90 lb (40.8 kg) |
| Rack Capacity (Rear) | 180 lb (82 kg) |
| Hitch Capacity | 2,500 lb (1,134 kg) |
| Dry Weight | 2,387 lbs (1,083 kg) |
| Gauges | Analog speedometer, Digital tachometer, odometer, trip meter, engine temp, low fuel lamp |
| Magneto | 650 W |
| Audio System | Includes 2 Standard 50 watt fairing speakers, 100 watts total. |
| Features | Audio System: JBL Trail Pro 2000 | Water Fording Height: Equal to the Floorboards | Other Standard: Premium Pro-Shield Cab; Doors with Power Windows; Tip-Out Glass Windshield with Wiper; Rear Glass Panel; Factory-Installed Heat, AC, Defrost; Rearview Mirror; Premium Steering Wheel and Interior Accents; NorthStar Tailgate Badge; Front Bumper with Integrated Winch, Plow & LED Mounts; Premium Cut & Sew Seats with Contoured Seatbacks and Embroidered Polaris Branding; Polaris HD 4500 lb Synthetic Rope Winch with Autostop and Wireless Remote; Polaris PulseElectrical System (6-Position) Underhood Busbar and 6-Position Roof Busbar; 12V Accessory Outlet; Battery Trickle-Charging Outlet; USB Outlet |
| Lighting | Dual LED Headlights, 1250lm Low Beam, 2300lm High Beam, Dual LED Tail Lights |
| Warranty | One Year: Unlimited-mileage, limited warranty |
| Steering | Tilt: Standard |
| Cage Type | Profiled cage, ROPS approved |
| Instrumentation | 7" Display Powered by RIDE COMMAND: Plow Mode, Group Ride, GPS Navigation, Bluetooth, AM/FM Radio; Dual-sweep Analog Dials w/ 4" LCD Rider Information Center: User Selectable Blue/Red Backlighting & Brightness, Programmable Service Intervals, Speedometer, Tachometer, Odometer, Tripmeter, Clock, Hour Meter, Gear Indicator, Fuel Gauge, Coolant Temperature, Voltmeter, Service Indicator and Codes, Seat Belt Reminder, 2 DC Outlets, USB Charge Port, Automatic Speed Limiting in 2 mph increments starting at 16 mph to max speed. |
