Drivetrain
| Transmission | Rotax® DCT, 7 Speed with High & Extra Low range |
| Transmission Type | Chain (final drive) |
| Clutch | Wet multi-disc, manual. Assist and Slipper. |
| Gearbox | 6-speed |
| Chain Type | #530 Chain; 16T/43T |
| Gear Ratios 1st | 10.169:1 |
| Gear Ratios 2nd | 6.933:1 |
| Gear Ratios 3rd | 5.151:1 |
| Gear Ratios 4th | 4.105:1 |
| Gear Ratios 5th | 3.508:1 |
| Gear Ratios 6th | 3.017:1 |
Suspension
| Front Suspension | Forged Aluminum heavy duty Tall Knuckle Double A-arm with sway bar |
| Rear Suspension | 4 Link Trailing arm with Forged Aluminum heavy duty Tall Knuckle |
| Front Shocks | FOX 2.5 PODIUM Piggyback with QS3 compression adjustment and bottom-out control |
| Rear Shocks | FOX 3.0 PODIUM RC2 Piggyback with bypass, dual-speed compression and rebound adjustments |
| Front Travel | 7.3 in (185 mm) |
| Rear Travel | 8.5 in (216 mm) |
Brakes
| Front Braking System | 32 mm hydraulic triple piston caliper with a 265 mm disc |
| Rear Braking System | 30 mm hydraulic twin piston caliper with a 255 mm disc |
| Parking Brake | Park In-Transmission / Lockable Hand Lever |
Tires
| Front Tire | ITP Tenacity XNR 32 x 10 x 16 in. |
| Rear Tire | ITP Tenacity XNR 32 x 10 x 16 in. |
| Wheels | 16 in. aluminum flow formed |
| Front Wheel | 10-Spoke Machined Cast 19" x 3.5" |
| Rear Wheel | 10-Spoke Machined Cast 16" x 5" |
Dimensions
| Overall Vehicle Size | 63" w x 76.6" h |
| Seat Height | 36.3 in (922 mm) |
| Rake / Trail | 23° / 4" |
| Wheelbase | 142.5 in (3,650 mm) |
| Ground Clearance | 17 in (432 mm) |
| Bed Box Dimensions | 27.5 x 43.1 x 11.6 in (69.8 x 109 x 29.5 cm) |
| Lean Angle (Left) | 31 |
| Lean Angle (Right) | 31 |
Capacities
| Fuel Capacity | 13.2 gal (50 L) |
| Seating Capacity | 0 |
| Hitch Type | Standard 1.25 in (3.2 cm) Receiver |
| Hitch Capacity | 1,350 lb (612 kg) |
| Cargo System | Lock & Ride Compatible 5 Gal (18.9L) Front Dry Storage |
| Payload Capacity | 220 lbs (485 kg) |
| Box Capacity | 600 lb (272 kg) Rear Dumping Box |
| Towing Capacity | 1,134 lbs (2,500 kg) |
| Bed Capacity | 1000 pounds for 49-state models |
| Cargo Capacity | 199 lbs (438 kg) |
| Storage Capacity | 2.1 gal (8.1 L) |
| Rack Capacity | 200 lb (90 kg) |
| Rack Capacity (Front) | 90 lb (40.8 kg) |
| Rack Capacity (Rear) | 180 lb (81.6 kg) |
Weights
| Dry Weight | 2,640 lbs (1,200 kg) |
Electronics
| Gauges | 4.5 in. wide digital display with keypad & 10.25 in. touchscreen display |
| Magneto | 1,700 W |
| Audio System | Includes 2 Standard 50 watt fairing speakers, 100 watts total. |
Lights & Safety
| Warranty | Factory: 6-month BRP limited warranty | Extended: B.E.S.T. term available up to 30 months |
| Steering | Power: Gen 2 Tri-mode DPS High torque |
| Features | Anti-Theft System: RF Digitally Encoded Security System (D.E.S.S.) with Start/Stop button |
| Lighting | Premium high-performance LED headlights Can-Am LED signature |
| Instrumentation | USB A (charging port & communication port) DC outlet (10-A) |
| Cage Type | High strength (Dual phase) steel tubing and stampings |
| Handlebars | Neken, aluminium 28/22 mm |
What type of fuel does a 2026 Can-Am Defender XT HD9 use?
A 2026 Can-Am Defender XT HD9 uses Unknown.
Does the 2026 Can-Am Defender XT HD9 have Automatic climate control?
No, the 2026 Can-Am Defender XT HD9 is not equipped with Automatic climate control.
Does the 2026 Can-Am Defender XT HD9 have Backup camera?
No, the 2026 Can-Am Defender XT HD9 is not equipped with Backup camera.
Does the 2026 Can-Am Defender XT HD9 have Heated seats?
No, the 2026 Can-Am Defender XT HD9 is not equipped with Heated seats.
Does the 2026 Can-Am Defender XT HD9 have Apple CarPlay?
No, the 2026 Can-Am Defender XT HD9 is not equipped with Apple CarPlay.
Does the 2026 Can-Am Defender XT HD9 have Android Auto?
No, the 2026 Can-Am Defender XT HD9 is not equipped with Android Auto.
Does the 2026 Can-Am Defender XT HD9 have Bluetooth?
No, the 2026 Can-Am Defender XT HD9 is not equipped with Bluetooth.
Does the 2026 Can-Am Defender XT HD9 have Keyless entry?
No, the 2026 Can-Am Defender XT HD9 is not equipped with Keyless entry.
Does the 2026 Can-Am Defender XT HD9 have Push start?
No, the 2026 Can-Am Defender XT HD9 is not equipped with Push start.
Does the 2026 Can-Am Defender XT HD9 have Navigation?
No, the 2026 Can-Am Defender XT HD9 is not equipped with Navigation.
Does the 2026 Can-Am Defender XT HD9 have Sunroof/moonroof?
No, the 2026 Can-Am Defender XT HD9 is not equipped with Sunroof/moonroof.
Does the 2026 Can-Am Defender XT HD9 have Leather seats?
No, the 2026 Can-Am Defender XT HD9 is not equipped with Leather seats.
Does the 2026 Can-Am Defender XT HD9 have Wireless phone charging?
No, the 2026 Can-Am Defender XT HD9 is not equipped with Wireless phone charging.
Does the 2026 Can-Am Defender XT HD9 have Adaptive cruise control?
No, the 2026 Can-Am Defender XT HD9 is not equipped with Adaptive cruise control.
Does the 2026 Can-Am Defender XT HD9 have Wifi hotspot?
No, the 2026 Can-Am Defender XT HD9 is not equipped with Wifi hotspot.
Does the 2026 Can-Am Defender XT HD9 have Third row seats?
No, the 2026 Can-Am Defender XT HD9 is not equipped with Third row seats.
Does the 2026 Can-Am Defender XT HD9 have Tow package?
No, the 2026 Can-Am Defender XT HD9 is not equipped with Tow package.
Does the 2026 Can-Am Defender XT HD9 have Head up display?
No, the 2026 Can-Am Defender XT HD9 is not equipped with Head up display.
Does the 2026 Can-Am Defender XT HD9 have Cooled seats?
No, the 2026 Can-Am Defender XT HD9 is not equipped with Cooled seats.
