Transmission Type | Shaft drive (cardan) |
Clutch | Seven-speed automatic DCT, plus reverse and walking mode |
Gearbox | 7-speed |
Transmission | Automatic PVT P/R/N/L/H In-line Shifting |
Chain Type | 2.2 : 1 |
Gear Ratios 1st | 9.403 : 1 |
Gear Ratios 2nd | 6.411 : 1 |
Gear Ratios 3rd | 4.763 : 1 |
Gear Ratios 4th | 3.796 : 1 |
Gear Ratios 5th | 3.243 : 1 |
Gear Ratios 6th | 2.789 : 1 |
Front Suspension | Sealed MacPherson Strut |
Rear Suspension | Sealed Dual A-Arm, IRS |
Front Travel | 7.9 in (201 mm) |
Rear Travel | 7.3 in (185 mm) |
Front Shocks | SACHS Big-Bore shocks |
Rear Shocks | SACHS Shock with self-leveling air preload adjustment |
Front Braking System | Single Lever 3-Wheel Hydraulic Disc with Hydraulic Rear Foot Brake |
Rear Braking System | Single Lever 3-Wheel Hydraulic Disc with Hydraulic Rear Foot Brake |
Parking Brake | Park In-Transmission / Lockable Hand Lever |
Front Tire | 25 x 8-12 P373; 6 PLY |
Rear Tire | 25 x 10-12 P373; 6 PLY |
Wheels | 12 in. (30.5 cm) Steel |
Front Wheel | Cast 19" x 3.5" |
Rear Wheel | Cast 16" x 5" |
Overall Vehicle Size | 48.8" w x 95.7" l x 50.1" h |
Seat Height | 35.2 in (895 mm) |
Rake / Trail | 29° / 5.2" |
Wheelbase | 56 in (1,432 mm) |
Ground Clearance | 11.5 in (290 mm) |
Lean Angle (Left) | 31 |
Lean Angle (Right) | 31 |
Bed Box Dimensions | 30.3 x 47.25 x 13.38 in (77 x 120 x 34 cm) |
Fuel Capacity | 6.75 gal (25.5 L) |
Hitch Type | Standard 1.25 in (3.2 cm) Receiver |
Cargo Capacity | 224 lbs (494 kg) |
Payload Capacity | 220 lbs (485 kg) |
Storage Capacity | 47 gal (177 L) |
Towing Capacity | 182 lbs (400 kg) |
Seating Capacity | 0 |
Rack Capacity (Front) | 90 lb (40.8 kg) |
Rack Capacity (Rear) | 180 lb (82 kg) |
Hitch Capacity | 1,350 lb (612 kg) |
Cargo System | Lock & Ride Compatible 5 Gal (18.9L) Front Dry Storage, 6 Gal (23 L) Rear Storage, Toolless Removable Passenger Seat |
Bed Capacity | 1,500 lbs. (680 kg) |
Box Capacity | 600 lb (272 kg) Rear Dumping Box |
Dry Weight | 785 lbs (356 kg) |
Gauges | 4" Analog Gauge with Speedometer, Indicator Lamps, and Multi-Function Display |
Magneto | 650-W |
Warranty | 3 year transferable, unlimited-mileage limited warranty; extended coverage available with a Honda Protection Plan. |
Steering | Power: Dynamic Power Steering (DPS) |
Features | Ride Modes, ABS, Keyless Ignition, 12V Charge Port, Rear Cylinder Deactivation |
Lighting | 50w High Beam, Dual 50w Low Beam Headlights, Dual Brake Lights/Tail Lights |
Instrumentation | All Digital Gauge, Speedometer, Odometer, Tachometer, 2 Tripmeters, Hour Meter, Gear Indicator, Fuel Gauge, AWD Indicator, Volt Meter, Coolant Temperature, Hi-Temp Light, Clock, DC Outlet |
Cage Type | Profiled cage ROPS approved |
