Gearbox | 6-speed |
Transmission | Automatic PVT P/R/N/L/H In-line Shifting |
Transmission Type | Chain (final drive) |
Clutch | Wet multi-disc, manual. Assist and Slipper. |
Chain Type | #520 Chain; 16T/45T |
Gear Ratios 1st | 9.403 : 1 |
Gear Ratios 2nd | 6.411 : 1 |
Gear Ratios 3rd | 4.763 : 1 |
Gear Ratios 4th | 3.796 : 1 |
Gear Ratios 5th | 3.243 : 1 |
Gear Ratios 6th | 2.789 : 1 |
Front Suspension | Sealed Arched Dual A-Arm |
Rear Suspension | Sealed Dual A-Arm, IRS |
Front Travel | 4.6 in (117 mm) |
Rear Travel | 3 in (76 mm) |
Front Shocks | FOX 2.5 PODIUM RC2 Piggyback with bypass and Smart-Shox Technology featuring Live Valve Gen 3 (Dual Valve compression & rebound) |
Rear Shocks | FOX 3.0 PODIUM RC2 Piggyback with bypass and Smart-Shox Technology featuring Live Valve Gen 3 (Dual Valve compression & rebound) |
Front Braking System | Single Lever 3-Wheel Hydraulic Disc with Hydraulic Rear Foot Brake |
Rear Braking System | Single Lever 3-Wheel Hydraulic Disc with Hydraulic Rear Foot Brake |
Parking Brake | Park In-Transmission / Lockable Hand Lever |
Front Wheel | Wire Wheel 16 in x 3 in |
Rear Wheel | Wire Wheel 16 in x 5 in |
Front Tire | 26 x 8-14; PXT |
Rear Tire | 26 x 10-14; PXT |
Wheels | 14 in. (35.6 cm) Aluminum |
Overall Vehicle Size | 28.7" w x 78.5" l x 44.1" h |
Seat Height | 33.2 in (845 mm) |
Rake / Trail | 0° |
Wheelbase | 50.5 in (1,283 mm) |
Ground Clearance | 11.5 in (290 mm) |
Bed Box Dimensions | 43.4 x 56 x 13.4 in (110.2 x 142.2 x 34 cm) |
Seating Capacity | 0 |
Fuel Capacity | 4.5 gal (17 L) |
Hitch Type | Standard 1.25 in (3.2 cm) Receiver |
Cargo Capacity | 454 lbs (1,000 kg) |
Payload Capacity | 220 lbs (485 kg) |
Storage Capacity | 2.1 gal (8.1 L) |
Towing Capacity | 1,134 lbs (2,500 kg) |
Hitch Capacity | 1,350 lb (612 kg) |
Cargo System | Lock & Ride Compatible 5 Gal (18.9L) Front Dry Storage, 6 Gal (27.3L) Rear Dry Storage |
Box Capacity | 1,500 lbs. (680 kg) |
Rack Capacity (Rear) | 180 lb (81.6 kg) |
Rack Capacity | 200 lb (90 kg) |
Bed Capacity | 1,500 lbs. (680 kg) |
Rack Capacity (Front) | 90 lb (40.8 kg) |
Dry Weight | 866 lbs (393 kg) |
Gauges | Speedometer, Tachometer, Odometer, Fuel Gauge, Compass, Ambient Temperature, Gear Indicator |
Magneto | 1700-W |
Warranty | 12 Month Limited Warranty |
Features | Other Standard: Front and Rear A-Arm Guards, Front Trail Bumper, Rear Trail Bumper, Front Rack Extender, Rear Rack Extender, 2,500 lb Polaris Winch, Dipped Camo Plastics, Upgraded Wheels & PXT Tires, Kolpin Gun Scabbard & Mount, Kolpin Ratchet Claws, Hand & Thumb Warmers, 12 Volt Power Plug, In Pod Battery Charger |
Lighting | High Output LED POD, High Output LED Bumper Lights, Dual LED Brake lights/Taillights |
Steering | Tilt & Telescoping |
Cage Type | High strength (Dual phase) steel tubing and stampings |
Instrumentation | All Digital Gauge, Speedometer, Odometer, Tachometer, Two Tripmeters, Hour Meter, Gear Indicator, Fuel Gauge, AWD Indicator, Volt Meter, Coolant Temperature, Hi-Temp Light |
