Transmission | Automatic PVT P/R/N/L/H |
Front Suspension | Light Weight Boxed Dual A-Arm with 3 piece Stabilizer Bar and 27.0 in (68.6 cm) *Usable Travel, 22.25 in (56.5 cm) Wheel Travel, Unitized Hubs |
Rear Suspension | Boxed Trailing Arm with Toe Link, High-Clearance Radius Rods, and 3 Piece Stabilizer Bar and 29.0 in (73.7 cm) *Usable Travel, 24.5 in (62.2 cm) Wheel Travel, Unitized Hubs |
Front Shocks | FOX 3.0 Live Valve X2 Internal Bypass (Electronically Controlled Compression and Rebound) |
Rear Shocks | FOX 3.0 Live Valve X2 Internal Bypass (Electronically Controlled Compression and Rebound) |
Front Braking System | 4-Wheel Hydraulic Disc with Triple-Bore |
Rear Braking System | 4-Wheel Hydraulic Disc Dual-Bore Rear Calipers |
Parking Brake | Park In-Transmission |
Wheels | 5-Lug, 15" Cast Aluminum Rim with Painted Beadlock |
Front Tire | 32 x 10-15 Maxxis Rampage Fury; 8-Ply Rated; Wheel Size 15x7 |
Rear Tire | 32 x 10-15 Maxxis Rampage Fury; 8-Ply Rated; Wheel Size 15x7 |
Overall Vehicle Size | 63" w x 152.2" l x 76.1" h |
Wheelbase | 104.5 in (2,654 mm) |
Ground Clearance | 16 in (406 mm) |
Bed Box Dimensions | 29.5 x 23.8 x 8.1 in (75 x 60.5 x 20.6 cm) |
Hitch Type | Standard 1.25 in (3.2 cm) Receiver |
Cargo System | Lock & Ride Factory Equipped Cargo Liner |
Payload Capacity | 336 lbs (740 kg) |
Fuel Capacity | 12 gal (45.4 L) |
Box Capacity | 300 lb (136.1 kg) |
Dry Weight | 2,327 lbs (1,056 kg) |
Warranty | 12 / Limited |
Steering | Power: Rack Mounted High Assist Electronic Power Steering with Quick Turn Rack; Race Inspired Steering Wheel with Tilt and Telescoping Adjustment; DYNAMIX DV with Integrated EPS Modes and Ride Command Push Button Controls |
Features | Doors: Vented Full Doors | Other Standard: High Output 900W Charging System with Sealed Electrical, Polaris Pulse System, In-Dash Charge Port, Polaris P.A.S.S. |
Lighting | Signature Animated RZR Fang Accent Lighting White LED, Low / High & Red LED Tail / Brake Lights and Interior Accent Lighting |
Instrumentation | RIDE COMMAND 7 Glove-Touch Display: DYNAMIX 2.0 Visualizer, Built-In GPS, Group ride (cell-based or GPS based), Topographic Mapping, Bluetooth & USB Smartphone Connectivity, AM/FM & Weather Radio (Accessory Speakers Required - Sold Separately), In-Vehicle Communications Capable With Optional Sena Headsets, Polaris P.A.S.S Anti-Theft System. Dual-sweep Analog Dials w/ 4" LCD Rider Information Center: User Selectable Blue/Red Backlighting & Brightness, Programmable Service Intervals. Digital Instrumentation: Speedometer, Tachometer, Odometer, Tripmeter, Clock, Hour Meter, Gear Indicator, Fuel Gauge, Coolant Temperature, Voltmeter, Service Indicator and Codes, Seat Belt Reminder Light, Gear Indicator, DC Outlet |
