Transmission | STEELDRIVE Automatic Transmission: D/R/P |
Clutch | Multi-plate with diaphragm spring in oil bath |
Gearbox | 6-speed |
Chain Type | #525 Chain; 15T/42T |
Gear Ratios 1st | 2.769 : 1 |
Gear Ratios 2nd | 1.882 : 1 |
Gear Ratios 3rd | 1.500 : 1 |
Gear Ratios 4th | 1.273 : 1 |
Gear Ratios 5th | 1.125 : 1 |
Gear Ratios 6th | 0.966 : 1 |
Transmission Type | Belt |
Front Suspension | Dual A-Arm |
Rear Suspension | Dual Arched A-Arm IRS |
Front Travel | 5.1 in (130 mm) |
Rear Travel | 5.4 in (137 mm) |
Front Shocks | FOX 2.0 Podium QS3 with Position Sensitive Spiral technology |
Rear Shocks | FOX 2.5 Podium QS3 with Position Sensitive Spiral technology |
Front Braking System | Foot activated and power assisted, 4 wheel hydraulic disc with dual-bore front and rear calipers |
Rear Braking System | Foot activated and power assisted, 4 wheel hydraulic disc with dual-bore front and rear calipers |
Parking Brake | Park In-Transmission |
Front Tire | 30 x 10-15; KENDA CROSS TRAIL | 8 Ply Rated |
Rear Tire | 30 x 11-15; KENDA CROSS TRAIL | 8 Ply Rated |
Front Wheel | Wire 40-Spoke 16" x 3.5" |
Rear Wheel | Wire 40-Spoke 16" x 3.5" |
Wheels | 15" Aluminum |
Overall Vehicle Size | 85.8" length |
Rake / Trail | 25.5° / 4" |
Wheelbase | 95 in (2,413 mm) |
Seat Height | 25.7 in |
Ground Clearance | 15 in (380 mm) |
Lean Angle (Left) | 33 |
Lean Angle (Right) | 33 |
Bed Box Dimensions | 43.4 x 56 x 13.4 in (110.2 x 142.2 x 34 cm) |
Fuel Capacity | 13.6 gal (51.5 L) |
Seating Capacity | 0 |
Hitch Type | Standard 2 in (5 cm) Receiver |
Hitch Capacity | 3,500 lbs. (1588 kg) |
Cargo System | Lock & Ride MAX |
Payload Capacity | 773 lbs (1,705 kg) |
Box Capacity | 1,500 lbs. (680 kg) |
Towing Capacity | 830 lbs (1,830 kg) |
Bed Capacity | 1,500 lbs. (680 kg) |
Cargo Capacity | 454 lbs (1,000 kg) |
Storage Capacity | 2.1 gal (8.1 L) |
Rack Capacity | 200 lb (90 kg) |
Rack Capacity (Front) | 120 lb (55 kg) |
Rack Capacity (Rear) | 240 lb (110 kg) |
Dry Weight | 2,800 lbs (1,270 kg) |
Gauges | Digital Speedometer, Digital Tachometer, Odometer, fuel gauge, compass, ambient temperature, Gear indicator |
Magneto | 1700-W |
Audio System | Upgraded PowerBand 2.0 Audio package Includes: 2 - 100 watt fairing speakers, 2 - 100 watt saddlebag speakers. 400 watts total. |
Features | Premium Pro-Shield Cab, Doors with Full Power Windows, Fixed Glass Windshield with Wiper, Rear Glass Panel, Dome Light, Door Puddle Lighting, Interior Accent Lighting, Rearview Mirror, Heat, AC, Defrost. Premium Contoured Seats with Additional Bolstering, Premium Headrests and Center Armrest. Premium, Telescoping Steering Wheel and Painted Interior Accents. Polaris Pulse Electrical System (6 position), Overhead Switch Panel, Roof Pulse Bar (6 position), 140 Amp Charging System, Front Bumper, DC Outlet, USB Charge Port, Trickle Charger, NFC Front Badge, NorthStar Badge. | Polaris Pro HD 6,000 Lb. Winch |
Lighting | LED Headlights w/ LED Taillights, LED Rear Work Light, LED Dome Light, Door Puddle Lighting, Interior Accent Lighting, Lighting Modes: Low, High, Accent, Blackout. Blackout mode switches off the headlights and dims interior lighting |
Warranty | |
Steering | Standard Tilt & Telescoping |
Instrumentation | Driver Forward Information Center w/ 4 in Color Display + Analog Speedometer & Tachometers: User Selectable Blue/Red Backlighting & Brightness, Speedometer, Tachometer, Odometer, Tripmeter, Clock, Hour Meter, Gear Indicator, Fuel Gauge, Coolant Temperature, Oil Pressure, Transmission Indicator, EPS Indicator, Voltmeter, Service Indicator and Codes, Seat Belt Reminder, Speed Limiting |
Handlebars | Aluminum |
Cage Type | High strength (Dual phase) steel tubing and stampings |
