Transmission | Chain (final drive) |
Transmission Type | Chain (final drive) |
Clutch | Wet, multi-plate |
Gearbox | 6-speed |
Chain Type | 2.2 : 1 |
Gear Ratios 1st | 9.403 : 1 |
Gear Ratios 2nd | 6.411 : 1 |
Gear Ratios 3rd | 4.763 : 1 |
Gear Ratios 4th | 3.796 : 1 |
Gear Ratios 5th | 3.243 : 1 |
Gear Ratios 6th | 2.789 : 1 |
Front Suspension | Inverted Telescopic Fork |
Rear Suspension | Dual Shocks |
Front Travel | 5.9 in (150 mm) |
Rear Travel | 5.5 in (140 mm) |
Front Shocks | FOX 2.0 Podium QS3 with Position Sensitive Spiral technology |
Rear Shocks | FOX 2.5 Podium QS3 with Position Sensitive Spiral technology |
Front Braking System | Dual Brembo / 320mm Semi-Floating Rotor / 4 Piston Caliper |
Rear Braking System | Single / 298mm Floating Rotor / 2 Piston Calipe |
Parking Brake | Single Handle Bar Mounted |
Wheels | Stamped Steel |
Front Tire | Metzeler Cruisetec 130/60 B19 61H |
Rear Tire | Metzeler Cruisetec 180/65 B16 81H |
Front Wheel | Machine Highlighted Cast Black 19 in x 3.5 in |
Rear Wheel | Machine Highlighted Cast Black 16 in x 5 in |
Seat Height | 27 in (686 mm) |
Overall Vehicle Size | 34.3" w x 90.6" l x 50" h |
Rake / Trail | 28° / 4.4" |
Wheelbase | 64.6 in (1,640 mm) |
Ground Clearance | 5 in (128 mm) |
Lean Angle (Left) | 31 |
Lean Angle (Right) | 31 |
Bed Box Dimensions | 21 x 42 x 5" (53.3 x 106.7 x 12.7 cm) |
Seating Capacity | 2 |
Fuel Capacity | 4 gal (15.1 L) |
Towing Capacity | 830 lbs (1,830 kg) |
Bed Capacity | 299 pounds |
Cargo System | Lock & Ride |
Payload Capacity | 170 lbs (375 kg) |
Rack Capacity (Front) | 120 lb (55 kg) |
Rack Capacity (Rear) | 240 lb (110 kg) |
Hitch Type | Standard 2 in (5 cm) Receiver |
Hitch Capacity | 2,500 lb (1,134 kg) |
Cargo Capacity | 204 lbs (449 kg) |
Storage Capacity | 1.85 gal (7 L) |
Box Capacity | 50 lb (22.7 kg) |
Rack Capacity | Front: 120 lb (54.4 kg) / Rear: 240 lb (109 kg) |
Dry Weight | 370 lbs |
Gauges | Speedometer, Tachometer, Odometer, Fuel Gauge, Compass, Ambient Temperature, Gear Indicator |
Magneto | 850-W |
Audio System | Includes 4 Standard 50 watt speakers. 2 in the fairing, 2 in the trunk. 200 watts total. |
Warranty | 2 Years, Unlimited Miles |
Features | ABS, Ride Modes, Keyless Ignition, 90 Watt Audio System with Bluetooth, Smartphone Compatible Input, USB charge port, 12V Charge Port, Rear Cylinder Deactivation |
Lighting | LED Headlight, LED Tail/Brake/Turn Signals |
Instrumentation | Digital Display with Gear Indicator, Odometer, Trip Meter, Voltage, Engine Temperature, Engine Hour Interval, Ground Speed, Engine RPM |
Steering | Tilt: Standard |
Handlebars | Aluminum |
Cage Type | Dual-phase 980 steel |
