Transmission | Manual |
Transmission Type | Chain (final drive) |
Clutch | Wet, Multi-Plate |
Gearbox | 6-speed |
Chain Type | 2.2 : 1 |
Gear Ratios 1st | 9.403 : 1 |
Gear Ratios 2nd | 6.411 : 1 |
Gear Ratios 3rd | 4.763 : 1 |
Gear Ratios 4th | 3.796 : 1 |
Gear Ratios 5th | 3.243 : 1 |
Gear Ratios 6th | 2.789 : 1 |
Front Suspension | Inverted Telescopic Fork |
Rear Suspension | Dual Shocks |
Front Travel | 5.1 in (130 mm) |
Rear Travel | 5.1 in (130 mm) |
Front Shocks | FOX 2.5 PODIUM RC2 Piggyback with bypass, dual speed compression and rebound adjustments |
Rear Shocks | FOX 3.0 PODIUM RC2 Piggyback with bypass, dual-speed compression and rebound adjustments |
Front Braking System | Dual Brembo / 320mm Semi-Floating Rotor / 4 Piston Caliper |
Rear Braking System | Single / 298mm Floating Rotor / 2 Piston Caliper |
Parking Brake | Park In-Transmission |
Wheels | 16 in. Aluminum Flow Formed Beadlock |
Front Tire | Metzeler Cruisetec 130/60B19 61H |
Rear Tire | Metzeler Cruisetec 180/65 B16 81H |
Front Wheel | Sport Cast Black 19 in x 3.5 in |
Rear Wheel | Sport Cast Black 16 in x 5 in |
Overall Vehicle Size | 33" w x 90.6" l x 50" h |
Seat Height | 27 in (686 mm) |
Wheelbase | 64.6 in (1,640 mm) |
Ground Clearance | 5 in (128 mm) |
Rake / Trail | 28° / 4.4" |
Lean Angle (Left) | 28.5 |
Lean Angle (Right) | 28.5 |
Bed Box Dimensions | 27.5 x 43.1 x 11.6 in (69.8 x 109 x 29.5 cm) |
Hitch Type | 2 in. hitch receiver |
Hitch Capacity | 1,500 lb (680 kg) |
Cargo System | Lock & Ride |
Payload Capacity | 712 lbs (1,570 kg) |
Fuel Capacity | 4 gal (15.1 L) |
Rack Capacity (Front) | 120 lb (54.4 kg) |
Rack Capacity (Rear) | 240 lb (109 kg) |
Seating Capacity | 0 |
Box Capacity | 600 lb (272 kg) Rear Dumping Box |
Storage Capacity | 2.1 gal (8.1 L) |
Towing Capacity | 1,134 lbs (2,500 kg) |
Bed Capacity | 600 lb (272 kg) Rear Dumping Box |
Cargo Capacity | 454 lbs (1,000 kg) |
Rack Capacity | 200 lb (90 kg) |
Dry Weight | 467 lbs (211.8 kg) |
Gauges | Speedometer, Tachometer, Odometer, Fuel Gauge, Compass, Ambient Temperature, Gear Indicator |
Audio System | Upgraded PowerBand 2.0 Audio package Includes: 2 - 100 watt fairing speakers, 2 - 100 watt saddlebag speakers. 2- 100 watt trunk speakers. 600 watts total. |
Magneto | 1700-W |
Warranty | 2 Years, Unlimited Miles |
Features | ABS, Ride Modes, Keyless Ignition, USB charge port, 12V Charge Port, Rear Cylinder Deactivation |
Lighting | LED Headlight, LED Tail/Brake/Turn Signals |
Instrumentation | USB A (charging port & communication port) DC outlet (10-A) |
Steering | Power: Gen 2 Tri-mode DPS High torque |
Cage Type | High strength (Dual phase) steel tubing and stampings |
Handlebars | Neken, aluminium 28/22 mm |
