Transmission | Manual |
Clutch | Wet, Multi-Plate |
Gearbox | 6-speed |
Chain Type | 2.2 : 1 |
Gear Ratios 1st | 9.403 : 1 |
Gear Ratios 2nd | 6.411 : 1 |
Gear Ratios 3rd | 4.763 : 1 |
Gear Ratios 4th | 3.796 : 1 |
Gear Ratios 5th | 3.243 : 1 |
Gear Ratios 6th | 2.789 : 1 |
Transmission Type | Belt |
Front Suspension | Inverted Telescopic Fork |
Rear Suspension | Dual Shocks |
Front Shocks | 2" Walker Evans Needle Shocks with 16-Position Adjustable Clickers |
Rear Shocks | 2.5" Walker Evans Needle Shocks with 16-Position Adjustable Clickers |
Front Travel | 5.1 in (130 mm) |
Rear Travel | 4.5 in (114 mm) |
Front Braking System | Dual Brembo / 320mm Semi-Floating Rotor / 4 Piston Caliper |
Rear Braking System | Single / 298mm Floating Rotor / 2 Piston Caliper |
Parking Brake | Park In-Transmission |
Wheels | Sport Cast Black wheels. Metzeler Cruisetec tires |
Front Tire | Metzeler Cruisetec 130/60B19 61H |
Rear Tire | Metzeler Cruisetec 180/65 B16 81H |
Front Wheel | Sport Cast Black 19 in x 3.5 in |
Rear Wheel | Sport Cast Black 16 in x 5 in |
Wheelbase | 64.6 in (1,640 mm) |
Ground Clearance | 5 in (128 mm) |
Bed Box Dimensions | 28 x 22 x 7 in (72.0 x 57.0 x 17.8 cm) |
Overall Vehicle Size | 33" w x 90.6" l x 50" h |
Seat Height | 27 in (686 mm) |
Rake / Trail | 28° / 4.4" |
Lean Angle (Left) | 31 |
Lean Angle (Right) | 31 |
Hitch Type | 2 in. hitch receiver |
Hitch Capacity | 2,500 lb (1,134 kg) |
Cargo System | Lock & Ride |
Payload Capacity | 336 lbs (740 kg) |
Fuel Capacity | 4 gal (15.1 L) |
Box Capacity | 300 lb (136 kg) |
Cargo Capacity | 454 lbs (1,000 kg) |
Storage Capacity | 11.1 gal (42.1 L) |
Towing Capacity | 1,134 lbs (2,500 kg) |
Bed Capacity | 1000 pounds (49 states) |
Seating Capacity | 0 |
Rack Capacity | Rear: 35 lb (16 kg) |
Rack Capacity (Front) | 90 lb (40.8 kg) |
Rack Capacity (Rear) | 180 lb (81.6 kg) |
Dry Weight | 795.9 lbs (361 kg) |
Gauges | Speedometer, Tachometer, Odometer, Fuel Gauge, Compass, Ambient Temperature, Gear Indicator |
Magneto | 650 W |
Audio System | Includes 2 Standard 50 watt fairing speakers, 100 watts total. |
Steering | Tilt: Standard Tilt |
Features | ABS, Ride Modes, Keyless Ignition, USB charge port, 12V Charge Port, Rear Cylinder Deactivation |
Lighting | LED Headlight, LED Tail/Brake/Turn Signals |
Instrumentation | Infotainment: A 7" Display Powered by RIDE COMMAND with Turn-by-Turn GPS Navigation, Customizable Gauge Screens, Bluetooth Connectivity, AM/FM Radio, Selectable Ride Modes, and More; Factory-Installed RIDE COMMAND+ Telecommunications Unit (TCU) for One-Year FREE Provides Live Weather and Traffic Overlays, Apple CarPlay, Bike Health, Bike Locator, Intuitive Destination Search, and More | |
Cage Type | Profiled cage, ROPS approved |
Warranty | 2 Years, Unlimited Miles |
Handlebars | Aluminium, tapered 28/22 mm |
