Chain Type | 2.379:1 |
Clutch | Wet, Multi-Plate, Assist |
Gear Ratios 1st | 10.169:1 |
Gear Ratios 2nd | 6.933:1 |
Gear Ratios 3rd | 5.151:1 |
Gear Ratios 4th | 4.105:1 |
Gear Ratios 5th | 3.508:1 |
Gear Ratios 6th | 3.017:1 |
Transmission | |
Gearbox | 6-speed |
Transmission Type | Belt |
Front Suspension | Inverted Telescopic Fork |
Rear Suspension | Single Shock w/ Hydraulic Preload Adjustment |
Front Shocks | Twin tube gas-charged shocks |
Rear Shocks | Twin tube gas-charged shocks |
Front Travel | 8.5 in (215 mm) |
Rear Travel | 10.6 in (270 mm) |
Front Braking System | Brembo Calipers, Dual Semi-Floating Rotors: 320mm x 5.0mm |
Rear Braking System | Single Floating Rotor: 298mm x 7.0mm |
Parking Brake | Park In-Transmission |
Front Wheel | Metzeler Cruisetec 130/60B19 66H |
Rear Wheel | 10-Spoke Machined Cast 19" x 3.5" |
Front Tire | Metzeler Cruisetec 130/60B19 66H |
Rear Tire | 10-Spoke Machined Cast 19" x 3.5" |
Wheels | Enforcer II Cast Aluminum wheels. Dunlop® Harley-Davidson Series, bias blackwall tires. |
Overall Vehicle Size | 41.9" w x 98.5" l x 48.7" h |
Rake / Trail | 25° / 5.9" |
Wheelbase | 65.7 in (2 mm) |
Seat Height | 26.5 in (686 mm) |
Ground Clearance | 5.4 in (137 mm) |
Bed Box Dimensions | 29.5 x 23.8 x 8.1 in (75 x 60.5 x 20.6 cm) |
Lean Angle (Left) | 31 |
Lean Angle (Right) | 31 |
Fuel Capacity | 6 gal (22.7 L) |
Seating Capacity | 4 |
Hitch Type | 2 in. hitch receiver |
Cargo System | Lock & Ride Factory Equipped Cargo Liner |
Payload Capacity | 680 lbs (1,500 kg) |
Box Capacity | 300 lb (136.1 kg) |
Hitch Capacity | 1500 lb (680 kg) |
Rack Capacity (Front) | 33 pounds |
Rack Capacity (Rear) | 800 lb. (363 kg) |
Bed Capacity | 1000 pounds (49 states) |
Storage Capacity | 16.2 gal (61.3 L) |
Towing Capacity | 1,134 lbs (2,500 kg) |
Rack Capacity | Rear: 35 lb (16 kg) |
Cargo Capacity | 454 lbs (1,000 kg) |
Dry Weight | 802 lbs (363.8 kg) |
Gauges | Fairing-mounted instrument cluster featuring analog speedometer and tachometer with fuel gauge, range, odometer and current gear. 15 LED telltale indicators: cruise control enabled, cruise control set, neutral, high beam, turn signal, ABS, check engine, low tire pressure, battery, low fuel, security system, low engine oil pressure and MPH or km/h unit designation. |
Magneto | 650 W |
Audio System | Upgraded PowerBand 2.0 Audio package Includes: 2 - 100 watt fairing speakers, 2 - 100 watt saddlebag speakers. 400 watts total. |
Features | A 7" Display Powered by RIDE COMMAND with Turn-by-Turn GPS Navigation, Customizable Gauge Screens, Bluetooth Connectivity, AM/FM Radio, Selectable Ride Modes, and More; Factory-Installed RIDE COMMAND+ Telecommunications Unit (TCU) for One-Year FREE Provides Live Weather and Traffic Overlays, Apple CarPlay, Bike Health, Bike Locator, Intuitive Destination Search, and More |
Lighting | LED Headlamp/Tail/Brake/Turn Signal |
Warranty | Factory: 2 Years, Unlimited Miles |
Steering | Power: Dynamic Power Steering (DPS) |
Instrumentation | Infotainment: A 7" Display Powered by RIDE COMMAND with Turn-by-Turn GPS Navigation, Customizable Gauge Screens, Bluetooth Connectivity, AM/FM Radio, Selectable Ride Modes, and More; Factory-Installed RIDE COMMAND+ Telecommunications Unit (TCU) for One-Year FREE Provides Live Weather and Traffic Overlays, Apple CarPlay, Bike Health, Bike Locator, Intuitive Destination Search, and More | |
Cage Type | Profiled cage, ROPS approved |
Handlebars | Aluminum |
