| Transmission | Automatic PVT P/R/N/L/H |
| Clutch | Wet, Multi-Plate, Assist |
| Gearbox | 6-speed |
| Chain Type | 2.379:1 |
| Gear Ratios 1st | 10.169:1 |
| Gear Ratios 2nd | 6.933:1 |
| Gear Ratios 3rd | 5.151:1 |
| Gear Ratios 4th | 4.105:1 |
| Gear Ratios 5th | 3.508:1 |
| Gear Ratios 6th | 3.017:1 |
| Front Suspension | Inverted Telescopic Fork |
| Rear Suspension | Single Shock w/ Hydraulic Preload Adjustment |
| Front Shocks | 2" Walker Evans Needle Shocks with 16-Position Adjustable Clickers |
| Rear Shocks | 2.5" Walker Evans Needle Shocks with 16-Position Adjustable Clickers |
| Front Travel | 16 in (406 mm) |
| Rear Travel | 18 in (457 mm) |
| Front Braking System | Brembo Calipers, Dual Semi-Floating Rotors: 320mm x 5.0mm |
| Rear Braking System | Single Floating Rotor: 298mm x 7.0mm |
| Parking Brake | Park In-Transmission |
| Wheels | Cast Aluminum |
| Front Tire | Metzeler Cruisetec 130/60B19 66H |
| Rear Tire | Metzeler Cruisetec 180/60R16 80H |
| Front Wheel | 10-Spoke Machined Cast 19" x 3.5" |
| Rear Wheel | 10-Spoke Machined Cast 16" x 5" |
| Overall Vehicle Size | 41.9" w x 98.5" l x 48.7" h |
| Rake / Trail | 25° / 5.9" |
| Wheelbase | 65.7 in (2 mm) |
| Seat Height | 26.5 in (686 mm) |
| Ground Clearance | 5.4 in (137 mm) |
| Lean Angle (Left) | 31 |
| Lean Angle (Right) | 31 |
| Bed Box Dimensions | 28 x 22 x 7 in (72.0 x 57.0 x 17.8 cm) |
| Fuel Capacity | 6 gal (22.7 L) |
| Hitch Type | Standard 1.25 in (3.2 cm) Receiver |
| Cargo System | Lock & Ride |
| Payload Capacity | 408 lbs (900 kg) |
| Box Capacity | 300 lb (136 kg) |
| Storage Capacity | 10.6 gal (40 L) |
| Towing Capacity | 830 lbs (1,830 kg) |
| Rack Capacity (Front) | 120 lb (54.4 kg) |
| Rack Capacity (Rear) | 240 lb (109 kg) |
| Dry Weight | 1,865 lbs (846 kg) |
| Gauges | Fairing-mounted instrument cluster featuring analog speedometer and tachometer with fuel gauge, range, odometer and current gear. 15 LED telltale indicators: cruise control enabled, cruise control set, neutral, high beam, turn signal, ABS, check engine, low tire pressure, battery, low fuel, security system, low engine oil pressure and MPH or km/h unit designation. |
| Audio System | Upgraded PowerBand 2.0 Audio package Includes: 2 - 100 watt fairing speakers, 2 - 100 watt saddlebag speakers. 400 watts total. |
| Lighting | LED Headlamp/Tail/Brake/Turn Signal |
| Instrumentation | Dual-sweep Analog Dials w/ 4" LCD Rider Information Center: User Selectable Blue/Red Backlighting & Brightness, Programmable Service Intervals, Speedometer, Tachometer, Odometer, Tripmeter, Clock, Hour Meter, Gear Indicator, Fuel Gauge, Coolant Temperature, Voltmeter, Service Indicator and Codes, Seat Belt Reminder Light, Gear Indicator, DC Outlet |
| Features | Remote Locking Hard Saddlebags, Power Adjustable Windshield, 18+ Gallons of Storage, Keyless Ignition, Adjustable Fairing Vents, USB Charger, Tire Pressure Monitoring System (TPMS) |
| Warranty | 2 Years, Unlimited Miles |
| Steering | Tilt: Standard Tilt |
Information deemed reliable, but not guaranteed. Interested parties should confirm all data before relying on it to make a purchase decision. All prices and specifications are subject to change without notice. Every price we list INCLUDES destination and assembly (sometimes referred to as freight and set-up), reconditioning, documentation, and dealer handling. The ONLY thing additional you will pay for is accessories, taxes and/or government fees. There are no surprise fees when you pay for your motorcycle, ATV or Side by Side. Please note picture shown may not depict actual unit and may show added accessories that do not come standard.
