Transmission Type | Chain (final drive) |
Clutch | Wet, Multi-Plate, Assist |
Gearbox | 6-speed |
Transmission | Chain (final drive) |
Chain Type | 2.2 : 1 |
Gear Ratios 1st | 9.403 : 1 |
Gear Ratios 2nd | 6.411 : 1 |
Gear Ratios 3rd | 4.763 : 1 |
Gear Ratios 4th | 3.796 : 1 |
Gear Ratios 5th | 3.243 : 1 |
Gear Ratios 6th | 2.789 : 1 |
Front Suspension | Telescopic Fork |
Rear Suspension | Single Shock w/ Air adjust |
Front Shocks | 2" Walker Evans Needle Shocks with 16-Position Adjustable Clickers |
Rear Shocks | 2.5" Walker Evans Needle Shocks with 16-Position Adjustable Clickers |
Front Travel | 16 in (406 mm) |
Rear Travel | 18 in (457 mm) |
Front Braking System | Dual / 300mm floating rotor / with 4-piston calipers |
Rear Braking System | Single / 300 mm Floating Rotor / 2 Piston Caliper |
Parking Brake | Park In-Transmission |
Front Wheel | 10-Spoke Contrast Cut 19 in x 3.5 in |
Rear Wheel | 10-Spoke Contrast Cut 16 in x 5 in |
Front Tire | Metzeler Cruisetec 130/60B19 66H |
Rear Tire | Metzeler Cruisetec 180/60R16 80H |
Wheels | Cast Aluminum |
Overall Vehicle Size | 40.3" w x 98.7" l x 51.6" h |
Seat Height | 27 in (686 mm) |
Rake / Trail | 25° / 5.9" |
Wheelbase | 65.7 in (1,668 mm) |
Ground Clearance | 5.1 in (130 mm) |
Bed Box Dimensions | 28 x 22 x 7 in (72.0 x 57.0 x 17.8 cm) |
Lean Angle (Left) | 31 |
Lean Angle (Right) | 31 |
Seating Capacity | 2 |
Fuel Capacity | 5.5 gal (20.8 L) |
Cargo Capacity | 136 lbs (300 kg) |
Storage Capacity | 5.3 gal (20.2 L) |
Towing Capacity | 680 lbs (1,500 kg) |
Hitch Type | 2 in. hitch receiver |
Payload Capacity | 336 lbs (740 kg) |
Cargo System | Lock & Ride |
Box Capacity | 300 lb (136 kg) |
Hitch Capacity | 1,350 lb (612 kg) |
Rack Capacity | Front: 100 lb (45 kg) / Rear: 700 lb (318 kg) |
Rack Capacity (Front) | 90 lb (40.8 kg) |
Rack Capacity (Rear) | 180 lb (81.6 kg) |
Dry Weight | 370 lbs |
Gauges | Fairing-Mounted Instrument Cluster with Analog Speedometer and Tachometer; Fuel Gauge, Range, Odometer and Current Gear |
Magneto | 650-W |
Warranty | Factory: 2 Years, Unlimited Miles |
Features | Standard Equipment: 7" Display powered by RIDE COMMAND with Navigation and Apple CarPlay integration; Power Windshield; Highway Bars; Vinyl Gunfighter Style Seat; Tire Pressure Monitoring; Remote-locking Hard Saddlebags; Selectable Ride Modes; Rear Cylinder Deactivation; ABS; Cruise Control; Keyless Ignition; 12V Charging Port |
Lighting | LED Headlamp/Tail/Brake/Turn Signal |
Instrumentation | 7 Display Powered by RIDE COMMAND: Rear View Camera, Digital Instrumentation, Built-In GPS, Group ride (cell-based or GPS based), Topographic Mapping, Bluetooth & USB Smartphone Connectivity, AM/FM & Weather Radio, In-Vehicle Communications Capable With Optional Sena Headsets Speedometer, Odometer, Tripmeter, Tachometer, Coolant Temperature, Volt Meter, Hour Meter, Service Indicator, Clock, Gear Indicator, Fuel Gauge, Hi-Temp Light, Seatbelt Reminder Light, Fault Code Display, DC Outlet, Ambient Temp |
Steering | Tilt: Standard Tilt |
Cage Type | Profiled cage ROPS approved |
