| Transmission | Close-ratio five-speed |
| Clutch | Wet, Multi-Plate, Assist |
| Gearbox | 5-speed |
| Chain Type | 2.379:1 |
| Gear Ratios 1st | 10.169:1 |
| Gear Ratios 2nd | 6.933:1 |
| Gear Ratios 3rd | 5.151:1 |
| Gear Ratios 4th | 4.105:1 |
| Gear Ratios 5th | 3.508:1 |
| Gear Ratios 6th | 3.017:1 |
| Front Suspension | Inverted Telescopic Fork |
| Rear Suspension | Single Shock w/ Hydraulic Preload Adjustment |
| Front Shocks | Walker Evans 2.5 Velocity Needle Shock with 16-Position Adjustable Clickers |
| Rear Shocks | Walker Evans 3.0 Velocity Needle Shock with 16-Position Adjustable Clickers |
| Front Travel | 12.2 in (310 mm) |
| Rear Travel | 12.2 in (310 mm) |
| Front Braking System | Brembo Calipers, Dual Semi-Floating Rotors: 320mm x 5.0mm |
| Rear Braking System | Single Floating Rotor: 298mm x 7.0mm |
| Parking Brake | Park In-Transmission |
| Wheels | Enforcer II Cast Aluminum. Dunlop® Harley-Davidson Series tires. |
| Front Tire | Metzeler Cruisetec 130/60B19 66H |
| Rear Tire | Metzeler Cruisetec 180/60R16 80H |
| Front Wheel | 10-Spoke Machined Cast 19" x 3.5" |
| Rear Wheel | 10-Spoke Machined Cast 16" x 5" |
| Wheelbase | 65.7 in (2 mm) |
| Ground Clearance | 5.4 in (137 mm) |
| Bed Box Dimensions | 26 x 17.7 x 11.5 in (66 x 45 x 29.2 cm) |
| Overall Vehicle Size | 41.9" w x 98.5" l x 48.7" h |
| Rake / Trail | 25° / 5.9" |
| Seat Height | 26.5 in (673 mm) |
| Lean Angle (Left) | 31 |
| Lean Angle (Right) | 31 |
| Seating Capacity | 0 |
| Hitch Type | Standard 1.25 in (3.2 cm) Receiver |
| Cargo System | Lock & Ride |
| Payload Capacity | 331 lbs (730 kg) |
| Fuel Capacity | 6 gal (22.7 L) |
| Box Capacity | 300 lb (136 kg) |
| Dry Weight | 249 lbs (112.9 kg) |
| Gauges | Fairing-mounted instrument cluster featuring analog speedometer and tachometer with fuel gauge, range, odometer and current gear. 15 LED telltale indicators: cruise control enabled, cruise control set, neutral, high beam, turn signal, ABS, check engine, low tire pressure, battery, low fuel, security system, low engine oil pressure and MPH or km/h unit designation. |
| Audio System | Includes 2 Standard 50 watt fairing speakers, 100 watts total. |
| Steering | Power: Rack Mounted High Assist Electronic Power Steering with Quick Turn Rack; Race Inspired Steering Wheel; RIDE COMMAND Push Button Controls |
| Features | Standard Equipment: Remote Locking Hard Saddlebags, Power Adjustable Windshield, 18+ Gallons of Storage, Keyless Ignition, Adjustable Fairing Vents, USB Charger, Tire Pressure Monitoring System (TPMS) |
| Lighting | LED Headlamp/Tail/Brake/Turn Signal |
| Instrumentation | Infotainment: A 7" Display Powered by RIDE COMMAND with Turn-by-Turn GPS Navigation, Customizable Gauge Screens, Bluetooth Connectivity, AM/FM Radio, Selectable Ride Modes, and More; Factory-Installed RIDE COMMAND+ Telecommunications Unit (TCU) for One-Year FREE Provides Live Weather and Traffic Overlays, Apple CarPlay, Bike Health, Bike Locator, Intuitive Destination Search, and More | |
| Warranty | Factory: 2 Years, Unlimited Miles |
Information deemed reliable, but not guaranteed. Interested parties should confirm all data before relying on it to make a purchase decision. All prices and specifications are subject to change without notice. Every price we list INCLUDES destination and assembly (sometimes referred to as freight and set-up), reconditioning, documentation, and dealer handling. The ONLY thing additional you will pay for is accessories, taxes and/or government fees. There are no surprise fees when you pay for your motorcycle, ATV or Side by Side. Please note picture shown may not depict actual unit and may show added accessories that do not come standard.
