Transmission | Belt (final drive) |
Clutch | Wet, Multi-Plate, Assist |
Gearbox | 6-speed |
Transmission Type | Belt (final drive) |
Chain Type | 2.379:1 |
Gear Ratios 1st | 10.169:1 |
Gear Ratios 2nd | 6.933:1 |
Gear Ratios 3rd | 5.151:1 |
Gear Ratios 4th | 4.105:1 |
Gear Ratios 5th | 3.508:1 |
Gear Ratios 6th | 3.017:1 |
Front Suspension | Inverted Telescopic Fork |
Rear Suspension | Single Shock w/ Hydraulic Preload Adjustment |
Front Shocks | SHOWA HPG piggyback 2.5 (dual-speed Compression, Dual-rate spring) |
Rear Shocks | SHOWA HPG piggyback 2.5 (dual-speed Compression, Dual-rate spring) |
Front Travel | 10.6 in (268 mm) |
Rear Travel | 10 in (254 mm) |
Front Braking System | Brembo Calipers, Dual Semi-Floating Rotors: 320mm x 5.0mm |
Rear Braking System | Single Floating Rotor: 298mm x 7.0mm |
Wheels | Aluminum |
Front Tire | Metzeler Cruisetec 130/60B19 66H |
Rear Tire | Metzeler Cruisetec 180/60R16 80H |
Front Wheel | 10-Spoke Machined Cast 19" x 3.5" |
Rear Wheel | 10-Spoke Machined Cast 16" x 5" |
Overall Vehicle Size | 41.9" w x 98.5" l x 48.7" h |
Wheelbase | 65.7 in (2 mm) |
Ground Clearance | 5.4 in (137 mm) |
Rake / Trail | 25° / 5.9" |
Seat Height | 26.5 in (673 mm) |
Lean Angle (Left) | 31 |
Lean Angle (Right) | 31 |
Storage Capacity | 2.5 gal (9.4 L) |
Fuel Capacity | 6 gal (22.7 L) |
Rack Capacity | 200 lb (91 kg) with LinQ quick-attach |
Seating Capacity | 2 |
Dry Weight | 370 lbs |
Gauges | Fairing-mounted instrument cluster featuring analog speedometer and tachometer with fuel gauge, range, odometer and current gear. 15 LED telltale indicators: cruise control enabled, cruise control set, neutral, high beam, turn signal, ABS, check engine, low tire pressure, battery, low fuel, security system, low engine oil pressure and MPH or km/h unit designation. |
Magneto | 650-W |
Audio System | Includes 2 Standard 50 watt fairing speakers, 100 watts total. |
Warranty | Factory: 2 Years, Unlimited Miles |
Steering | Power: High torque Tri-Mode Dynamic Power Steering (DPS) |
Cage Type | Dual-phase 980 steel |
Features | Standard Equipment: Remote Locking Hard Saddlebags, Power Adjustable Windshield, 18+ Gallons of Storage, Keyless Ignition, Adjustable Fairing Vents, USB Charger, Tire Pressure Monitoring System (TPMS) |
Lighting | LED Headlamp/Tail/Brake/Turn Signal |
Instrumentation | Infotainment: A 7" Display Powered by RIDE COMMAND with Turn-by-Turn GPS Navigation, Customizable Gauge Screens, Bluetooth Connectivity, AM/FM Radio, Selectable Ride Modes, and More; Factory-Installed RIDE COMMAND+ Telecommunications Unit (TCU) for One-Year FREE Provides Live Weather and Traffic Overlays, Apple CarPlay, Bike Health, Bike Locator, Intuitive Destination Search, and More | |
