Chain Type | 520 X-Ring |
Clutch | Wet multiplate with coil springs |
Gear Ratios 1st | 10.926 : 1 |
Gear Ratios 2nd | 7.427 : 1 |
Gear Ratios 3rd | 5.918 : 1 |
Gear Ratios 4th | 5.022 : 1 |
Gear Ratios 5th | 4.439 : 1 |
Gear Ratios 6th | 3.810 : 1 |
Transmission | pDrive primary and Quick Response System X (QRS-X) CVT with high airflow, L / H / N / R / P |
Gearbox | 6-speed |
Transmission Type | Chain (final drive) |
Front Suspension | Double A-arm with sway bar |
Rear Suspension | 4-link Torsional Trailing-arm X (TTX) with sway bar |
Front Travel | 16 in (406 mm) |
Rear Travel | 18 in (457 mm) |
Front Shocks | SHOWA HPG piggyback 2.5 (dual-speed Compression, Dual-rate spring) |
Rear Shocks | SHOWA HPG piggyback 2.5 (dual-speed Compression, Dual-rate spring) |
Front Braking System | Dual 262 mm disc brakes with hydraulic twin-piston calipers |
Rear Braking System | Dual 248 mm disc brakes with hydraulic twin-piston calipers |
Parking Brake | Park In-Transmission |
Front Wheel | Black Wire 16 in x 3.5 in |
Rear Wheel | Black Wire 16 in x 3.5 in |
Front Tire | XPS Trac Force 30 x 10 x 14 in. |
Rear Tire | XPS Trac Force 30 x 10 x 14 in. |
Wheels | 14 in. cast-aluminum |
Overall Vehicle Size | 30.9" w x 88.6" l x 43.3" h |
Rake / Trail | 24.5° / 4" |
Wheelbase | 135 in (3,429 mm) |
Seat Height | 28.9 in |
Ground Clearance | 13 in (330 mm) |
Bed Box Dimensions | 43.4 x 56 x 13.4 in (110.2 x 142.2 x 34 cm) |
Lean Angle (Left) | 29 |
Lean Angle (Right) | 29 |
Fuel Capacity | 10.5 gal (40 L) |
Seating Capacity | 2 |
Hitch Type | Standard 2 in (5 cm) Receiver |
Cargo System | Lock & Ride MAX |
Payload Capacity | 755 lbs (1,665 kg) |
Box Capacity | 1,500 lbs. (680 kg) |
Hitch Capacity | 3,500 lbs. (1588 kg) |
Cargo Capacity | 454 lbs (1,000 kg) |
Storage Capacity | 3 gal (11.4 L) |
Towing Capacity | 2,041 lbs (4,500 kg) |
Rack Capacity (Front) | 120 lb (55 kg) |
Rack Capacity (Rear) | 240 lb (110 kg) |
Rack Capacity | 150 lb (68 kg) with LinQ quick-attach |
Bed Capacity | 1,500 lbs. (680 kg) |
Dry Weight | 1,810 lbs (821 kg) |
Gauges | 4.5 in. digital display with keypad |
Magneto | 650-W |
Audio System | Upgraded PowerBand 2.0 Audio package Includes: 2 - 100 watt fairing speakers, 2 - 100 watt saddlebag speakers. 400 watts total. |
Features | Anti-Theft System: RF Digitally Encoded Security System (D.E.S.S.) with Start/Stop button |
Lighting | LED headlight, LED tail lights |
Warranty | Factory: 6-month BRP Limited warranty | Extended: B.E.S.T. term available up to 30 months |
Steering | Power: High torque Tri-Mode Dynamic Power Steering (DPS) |
Instrumentation | DC outlet (10-A) |
Handlebars | Aluminum |
Cage Type | Dual-phase 980 steel |
