Drivetrain
| Transmission | Rotax® DCT, 7 Speed with High & Extra Low range |
| Transmission Type | Belt |
| Clutch | Automatic |
| Gearbox | 6-speed |
| Chain Type | 2.2 : 1 |
| Gear Ratios 2nd | 6.411 : 1 |
| Gear Ratios 1st | 9.403 : 1 |
| Gear Ratios 3rd | 4.763 : 1 |
| Gear Ratios 4th | 3.796 : 1 |
| Gear Ratios 5th | 3.243 : 1 |
| Gear Ratios 6th | 2.789 : 1 |
Suspension
| Front Suspension | Forged Aluminum heavy duty Tall Knuckle Double A-arm with sway bar |
| Rear Suspension | 4 Link Trailing arm with Forged Aluminum heavy duty Tall Knuckle |
| Front Travel | 7.8 in (198 mm) |
| Rear Travel | 8.2 in (208 mm) |
| Front Shocks | FOX 2.5 PODIUM RC2 Piggyback with bypass, dual speed compression and rebound adjustments |
| Rear Shocks | FOX 3.0 PODIUM RC2 Piggyback with bypass, dual-speed compression and rebound adjustments |
Brakes
| Front Braking System | 32 mm hydraulic triple piston caliper with a 265 mm disc |
| Rear Braking System | 30 mm hydraulic twin piston caliper with a 255 mm disc |
| Parking Brake | Single Handle Bar Mounted, Mechanical Locking |
Tires
| Wheels | 16 in. Aluminum Flow Formed Beadlock |
| Front Tire | ITP Tenacity XNR 32 x 10 x 16 in. |
| Rear Tire | ITP Tenacity XNR 32 x 10 x 16 in. |
| Front Wheel | Cast Black 19 in x 3.5 in |
| Rear Wheel | Cast Black 16 in x 5 in |
Dimensions
| Wheelbase | 142.5 in (3,650 mm) |
| Ground Clearance | 17 in (432 mm) |
| Bed Box Dimensions | 43.4 x 56 x 13.4 in (110.2 x 142.2 x 34 cm) |
| Overall Vehicle Size | 62" w x 79.4" h |
| Seat Height | 26 in (662 mm) |
| Rake / Trail | 29° / 5.2" |
| Lean Angle (Left) | 28.5 |
| Lean Angle (Right) | 28.5 |
Capacities
| Cargo System | Lock & Ride Compatible 5 Gal (18.9L) Front Dry Storage |
| Payload Capacity | 771 lbs (1,700 kg) |
| Fuel Capacity | 13.2 gal (50 L) |
| Box Capacity | 1,000 lb (454 kg) |
| Cargo Capacity | 454 lbs (1,000 kg) |
| Storage Capacity | 2.1 gal (8.1 L) |
| Hitch Type | 2 in. hitch receiver |
| Hitch Capacity | 1,350 lb (612 kg) |
| Rack Capacity (Front) | 90 lb (40.8 kg) |
| Rack Capacity (Rear) | 25 lb (11.3 kg) |
| Seating Capacity | 0 |
| Bed Capacity | 450 pounds |
| Towing Capacity | 454 lbs (1,000 kg) |
| Rack Capacity | 200 lb (90 kg) |
Weights
| Dry Weight | 2,650 lbs (1,205 kg) |
Electronics
| Gauges | 4.5 in. wide digital display with keypad & 10.25 in. touchscreen display |
| Magneto | 1700-W |
| Audio System | Includes 4 Standard 50 watt speakers. 2 in the fairing, 2 in the trunk. 200 watts total. |
Lights & Safety
| Features | Anti-Theft System: RF Digitally Encoded Security System (D.E.S.S.) with Start/Stop button |
| Lighting | Premium high-performance LED headlights Can-Am LED signature |
| Instrumentation | USB A (charging port & communication port) DC outlet (10-A) |
| Warranty | Factory: 6-month BRP limited warranty | Extended: B.E.S.T. term available up to 30 months |
| Steering | Power: Gen 2 Tri-mode DPS High torque |
| Handlebars | Neken, aluminium 28/22 mm |
| Cage Type | High strength (Dual phase) steel tubing and stampings |
Frequently asked questions about 2025 Can-Am Maverick R Max X RS Dusty Navy & Legion Red
What type of fuel does a 2025 Can-Am Maverick R Max X RS Dusty Navy & Legion Red use?
A 2025 Can-Am Maverick R Max X RS Dusty Navy & Legion Red uses Gasoline.
What is the 2025 Can-Am Maverick R Max X RS Dusty Navy & Legion Red fuel capacity?
A 2025 Can-Am Maverick R Max X RS Dusty Navy & Legion Red has the fuel capacity of 13 gallons.
How much horsepower does a 2025 Can-Am Maverick R Max X RS Dusty Navy & Legion Red have?
A 2025 Can-Am Maverick R Max X RS Dusty Navy & Legion Red has 240 horsepower.
How is the 2025 Can-Am Maverick R Max X RS Dusty Navy & Legion Red cooled?
The 2025 Can-Am Maverick R Max X RS Dusty Navy & Legion Red is cooled by Liquid cooled with integrated intercooler and high-performance air filter.
What type of fuel system does the 2025 Can-Am Maverick R Max X RS Dusty Navy & Legion Red have?
The 2025 Can-Am Maverick R Max X RS Dusty Navy & Legion Red is equipped with a Intelligent Throttle Control (iTC) with Electronic Fuel Injection (EFI) fuel system.
What type of front brakes does the 2025 Can-Am Maverick R Max X RS Dusty Navy & Legion Red have?
The 2025 Can-Am Maverick R Max X RS Dusty Navy & Legion Red is equipped with 32 mm hydraulic triple piston caliper with a 265 mm disc front brakes.
What type of rear brakes does the 2025 Can-Am Maverick R Max X RS Dusty Navy & Legion Red have?
The 2025 Can-Am Maverick R Max X RS Dusty Navy & Legion Red is equipped with 30 mm hydraulic twin piston caliper with a 255 mm disc rear brakes.
