Transmission | PRO-TORQ CVT with Quick Response System (QRS), high-airflow ventilation and Electronic Drive Bel |
Transmission Type | Chain (final drive) |
Clutch | Wet multi-disc, manual. Assist and Slipper. |
Gearbox | 6-speed |
Chain Type | O-ring-sealed chain; 14T/36T |
Gear Ratios 2nd | 1.882 : 1 |
Gear Ratios 1st | 2.769 : 1 |
Gear Ratios 3rd | 1.500 : 1 |
Gear Ratios 4th | 1.273 : 1 |
Gear Ratios 5th | 1.125 : 1 |
Gear Ratios 6th | 0.966 : 1 |
Front Suspension | Arched double A-arm |
Rear Suspension | Arched TTA with external sway bar |
Front Travel | 10.6 in (268 mm) |
Rear Travel | 10 in (254 mm) |
Front Shocks | Twin tube gas-charged shocks |
Rear Shocks | Twin tube gas-charged shocks |
Front Braking System | Dual 220 mm disc brakes with hydraulic twin-piston calipers |
Rear Braking System | Dual 220 mm disc brakes with hydraulic single-piston calipers |
Parking Brake | Park In-Transmission |
Wheels | 14 in. cast aluminum | Steering: Adjustable tilt steering |
Front Tire | XPS Trail King 27 x 9 / 11 x 14 in. |
Rear Tire | XPS Trail King 27 x 9 / 11 x 14 in. |
Front Wheel | 10-spoke, Platinum silver, 16 x 4.5 in. (406 x 114 mm) |
Rear Wheel | 10-spoke, Platinum Silver, 16 x 6.5 in. (406 x 165 mm) |
Wheelbase | 83 in (2,115 mm) |
Ground Clearance | 13 in (330 mm) |
Bed Box Dimensions | 36.2 x 47.25 x 13.38 in (92 x 120 x 34 cm) |
Overall Vehicle Size | 28.7" w x 78.5" l x 44.1" h |
Seat Height | 30.9 in |
Rake / Trail | 28° / 4.3" |
Lean Angle (Left) | 33 |
Lean Angle (Right) | 33 |
Cargo System | Lock & Ride MAX |
Payload Capacity | 680 lbs (1,500 kg) |
Fuel Capacity | 10.6 gal (40 L) |
Box Capacity | 600 lb (272 kg) |
Cargo Capacity | 454 lbs (1,000 kg) |
Storage Capacity | 10.4 gal (39.5 L) |
Hitch Type | 2 in. hitch receiver |
Hitch Capacity | 2,000 lb (907 kg) |
Rack Capacity (Front) | 120 lb (55 kg) |
Rack Capacity (Rear) | 240 lb (110 kg) |
Seating Capacity | 0 |
Bed Capacity | 299 pounds |
Towing Capacity | 1,134 lbs (2,500 kg) |
Rack Capacity | Front: 120 lb (54.4 kg) / Rear: 240 lb (109 kg) |
Dry Weight | 1,558 lbs (707 kg) |
Gauges | 4.5 in. wide digital display |
Magneto | 650 W |
Audio System | Includes 4 Standard 50 watt speakers. 2 in the fairing, 2 in the trunk. 200 watts total. |
Features | POLARIS HD 4500 LB Winch w/ Rope, Rubber stopper & Aluminum Fairlead, AutoStop & Plow Mode, Front Bull Bumper, ProFit Sport Roof, Convex Rear View Mirror, JBL Trail Pro 4100 Audio, Rear View Camera, Enclosed ADV Back for Sealed Storage |
Lighting | Front lighting output 140 W LED tail lights |
Instrumentation | DC outlet (10 A) |
Warranty | Factory: 1 year BRP limited warranty | Extended: B.E.S.T. term available up to 30 months |
Steering | Power: Dynamic Power Steering (DPS) |
Handlebars | Neken, aluminium 28/22 mm |
Cage Type | Profiled cage, ROPS approved |
