Transmission | Manual |
Transmission Type | Chain (final drive) |
Clutch | Wet, Multi-Plate |
Gearbox | 6-speed |
Chain Type | 2.357 : 1 |
Gear Ratios 1st | 10.926 : 1 |
Gear Ratios 2nd | 7.427 : 1 |
Gear Ratios 3rd | 5.918 : 1 |
Gear Ratios 4th | 5.022 : 1 |
Gear Ratios 5th | 4.439 : 1 |
Gear Ratios 6th | 3.810 : 1 |
Front Suspension | Telescopic Fork |
Rear Suspension | Dual Shocks |
Front Travel | 7.8 in (198 mm) |
Rear Travel | 8.2 in (208 mm) |
Front Braking System | Single / 298 mm Rotor / 2 Piston Caliper |
Rear Braking System | Single / 298 mm Rotor / 1 Piston Caliper |
Front Wheel | Black Wire 16 in x 3.5 in |
Rear Wheel | Black Wire 16 in x 3.5 in |
Front Tire | Pirelli MT60RS 130/90B16 67H |
Rear Tire | Pirelli MT60RS 150/80B16 77H |
Wheels | Aluminum |
Seat Height | 25.6 in (649 mm) |
Overall Vehicle Size | 39.2" w x 87.5" l x 46.5" h |
Rake / Trail | 29° / 4.7" |
Wheelbase | 62 in (2 mm) |
Ground Clearance | 5.1 in (129 mm) |
Lean Angle (Left) | 29 |
Lean Angle (Right) | 29 |
Seating Capacity | 0 |
Fuel Capacity | 3.3 gal (12.5 L) |
Dry Weight | 1,627.3 lbs (738.1 kg) |
Gauges | Digital tachometer, odometer, trip meter, engine temp, low fuel lamp |
Audio System | Includes 2 Standard 50 watt fairing speakers, 100 watts total. |
Warranty | Factory: 2 Years, Unlimited Miles |
Lighting | Headlight, tail/brake light, turn signals, license plate light, speedometer and indicator lights |
Features | Standard Equipment: Wire wheels |
Instrumentation | Infotainment: A 7" Display Powered by RIDE COMMAND with Turn-by-Turn GPS Navigation, Customizable Gauge Screens, Bluetooth Connectivity, AM/FM Radio, Selectable Ride Modes, and More; Factory-Installed RIDE COMMAND+ Telecommunications Unit (TCU) for One-Year FREE Provides Live Weather and Traffic Overlays, Apple CarPlay, Bike Health, Bike Locator, Intuitive Destination Search, and More | |
