Transmission | Shaft drive (cardan) |
Transmission Type | Shaft drive (cardan) |
Clutch | Wet, Multi-Plate, Assist |
Gearbox | 5-speed |
Chain Type | 2.2 : 1 |
Gear Ratios 2nd | 6.411 : 1 |
Gear Ratios 1st | 9.403 : 1 |
Gear Ratios 3rd | 4.763 : 1 |
Gear Ratios 4th | 3.796 : 1 |
Gear Ratios 5th | 3.243 : 1 |
Gear Ratios 6th | 2.789 : 1 |
Front Suspension | Telescopic Fork |
Rear Suspension | Single Shock w/ Air adjust |
Front Shocks | Walker Evans 2.5 Velocity Needle Shock with 16-Position Adjustable Clickers |
Rear Shocks | Walker Evans 3.0 Velocity Needle Shock with 16-Position Adjustable Clickers |
Front Travel | 4.3 in (109 mm) |
Rear Travel | 3.8 in (97 mm) |
Front Braking System | Dual / 300 mm Floating Rotor / 4 Piston Caliper |
Rear Braking System | Single / 300 mm Floating Rotor / 2 Piston Caliper |
Parking Brake | Park In-Transmission |
Wheels | Aluminum |
Front Tire | Metzeler Cruisetec 130/80B17 65H |
Rear Tire | Metzeler Cruisetec 180/60R16 80H |
Front Wheel | Highlight Machine Tour 17 in x 3.5 in |
Rear Wheel | Highlight Machine Tour 16 in x 5 in |
Seat Height | 26.5 in (673 mm) |
Overall Vehicle Size | 40.2" w x 104.6" l x 55.7" h |
Rake / Trail | 25° / 5.9" |
Wheelbase | 65.7 in (1,668 mm) |
Ground Clearance | 5.5 in (140 mm) |
Bed Box Dimensions | 36.75 x 54.25 x 12.5 in (93 x 138 x 32 cm) |
Lean Angle (Left) | 31 |
Lean Angle (Right) | 31 |
Seating Capacity | 0 |
Fuel Capacity | 5.5 gal (20.8 L) |
Towing Capacity | 830 lbs (1,830 kg) |
Bed Capacity | 1,500 lbs. (680 kg) |
Hitch Type | Standard 2 in (5 cm) Receiver |
Hitch Capacity | 2,500 lb (1,134 kg) |
Cargo System | Lock & Ride |
Payload Capacity | 680 lbs (1,500 kg) |
Box Capacity | 1000 lbs (454 kg) |
Cargo Capacity | 187 lbs (412 kg) |
Storage Capacity | 1.85 gal (7 L) |
Rack Capacity | Front: 120 lb (54.4 kg) / Rear: 240 lb (109 kg) |
Rack Capacity (Front) | 120 lb (54.4 kg) |
Rack Capacity (Rear) | 800 lb. (363 kg) |
Dry Weight | 1,684 lbs (764 kg) |
Gauges | Fairing-mounted instrument cluster featuring analog speedometer and tachometer with fuel gauge, range, odometer and current gear. 15 LED telltale indicators; cruise control enabled, cruise control set, neutral, high beam, turn signal, ABS, check engine, low tire pressure, battery, low fuel, security system, low engine oil pressure and MPH or km/h unit designation. |
Magneto | 650 W |
Audio System | Includes 2 Standard 50 watt fairing speakers, 100 watts total. |
Warranty | Factory: 2 Years, Unlimited Miles |
Steering | Tilt: Standard |
Features | Standard Equipment: 7 in Display powered by RIDE COMMAND with Navigation and Apple CarPlay integration; Power Windshield; Driving Lights; Highway Bars; Vinyl Seats (Separate Rider/Passenger Heat Controls); Heated Grips; Adjustable Passenger Floorboards; 36.2 Gallons of Storage; Tire Pressure Monitoring; Remote-locking Hard Saddlebags & Trunk; Selectable Ride Modes; Rear Cylinder Deactivation; ABS; Cruise Control; Keyless Ignition; 200 Watt Audio System with AM/FM, Bluetooth, USB, Smartphone Compatible Input, and Weatherband; 12V Charging Port |
Lighting | LED Headlamp / Driving / Tail / Brake / Turn Signal |
Instrumentation | Dual-sweep Analog Dials w/ 4" LCD Rider Information Center: User Selectable Blue/Red Backlighting & Brightness, Programmable Service Intervals, Speedometer, Tachometer, Odometer, Tripmeter, Clock, Hour Meter, Gear Indicator, Fuel Gauge, Coolant Temperature, Voltmeter, Service Indicator and Codes, Seat Belt Reminder, DC Outlet, USB Charge Port, Automatic Speed Limiting in 2 mph increments starting at 16 mph to max speed. |
Handlebars | Aluminum |
Cage Type | Profiled cage, ROPS approved |
Headlight Type | LED |
