Transmission | |
Transmission Type | Belt |
Clutch | Wet, Multi-Plate |
Gearbox | 6-speed |
Chain Type | 2.2 : 1 |
Gear Ratios 1st | 9.403 : 1 |
Gear Ratios 2nd | 6.411 : 1 |
Gear Ratios 3rd | 4.763 : 1 |
Gear Ratios 4th | 3.796 : 1 |
Gear Ratios 5th | 3.243 : 1 |
Gear Ratios 6th | 2.789 : 1 |
Front Suspension | Telescopic Fork |
Rear Suspension | Dual Shocks w/adjustable preload |
Front Travel | 4.6 in (117 mm) |
Rear Travel | 3.5 in (89 mm) |
Front Braking System | Single / 300mm Semi-Floating Rotor / 4 Piston Caliper |
Rear Braking System | Single / 300mm Floating Rotor / 2 Piston Caliper |
Parking Brake | Park in Transmission/Lockable Hand Lever |
Front Wheel | Wire Spoke 16 in x 3 in |
Rear Wheel | Wire Spoke 16 in x 5 in |
Front Tire | Pirelli Night Dragon 130/90B16 67H |
Rear Tire | Pirelli Night Dragon 180/65 B16 81H |
Wheels | Wire spoked |
Seat Height | 26 in (662 mm) |
Overall Vehicle Size | 36" w x 90" l x 53.1" h |
Rake / Trail | 29° / 5.2" |
Wheelbase | 64 in (2 mm) |
Ground Clearance | 4.9 in (125 mm) |
Lean Angle (Left) | 28.5 |
Lean Angle (Right) | 28.5 |
Seating Capacity | 2 |
Fuel Capacity | 4 gal (15.1 L) |
Hitch Type | Standard/1.25" Receiver |
Hitch Capacity | 1,500 (680.4 kg) |
Cargo System | Integrated Front Storage Box and Lock & Ride |
Payload Capacity | 261 lbs (575 kg) |
Rack Capacity (Front) | 90 lb (40.8 kg) |
Rack Capacity (Rear) | 180 lb (81.6 kg) |
Dry Weight | 553.3 lbs |
Gauges | Electronic speedometer with odometer; dual tripmeters; digital tachometer; ambient air temperature; fuel range; average fuel economy; battery voltage; gear position display; real-time clock; vehicle trouble code readout; low engine oil pressure; and 9 LED telltale indicators: cruise control enabled, cruise control set, neutral, high beam, turn signal, ABS (if equipped), check engine, and MPH or km/h unit designation; electronic fuel gauge with low fuel indicator |
Warranty | Factory: 2 Years, Unlimited Miles |
Features | Other Standard: Front Trail Bumper, 2,500 lb. Polaris HD Winch, 12 Volt Power Plug, Pre-Wired for Hand & Thumb Warmers, In Pod Battery Charger, Painted Plastics, Front and Rear A-Arm Guards |
Lighting | LED Headlight, LED Tail/Brake/Turn Signals |
Instrumentation | Analog Speedometer, Digital Odometer, Tachometer, Two Tripmeters, Hour Meter, Clock, Service Indicator, Diagnostic Indicator, Gear Indicator, Fuel Gauge, AWD Indicator, Hi-Temp/Low-Batt Lights, DC Outlet |
