Transmission | Manual |
Chain Type | 2.379:1 |
Clutch | Wet, Multi-Plate, Assist |
Gear Ratios 1st | 10.169:1 |
Gear Ratios 2nd | 6.933:1 |
Gear Ratios 3rd | 5.151:1 |
Gear Ratios 4th | 4.105:1 |
Gear Ratios 5th | 3.508:1 |
Transmission Type | Chain |
Gearbox | 6-speed |
Gear Ratios 6th | 3.017:1 |
Front Suspension | Inverted Telescopic Cartridge Fork |
Rear Suspension | Fox Single Shock w/Hyd adjust |
Front Travel | 9 in (229 mm) |
Rear Travel | 10.3 in (260 mm) |
Front Braking System | Dual / 320mm Semi-Floating Rotor / 4 Piston Radial Caliper |
Rear Braking System | Single / 298mm Floating Rotor / 2 Piston Caliper |
Parking Brake | Park in Transmission/Lockable Hand Lever |
Front Wheel | Sport Contrast Cut with Indian Red Pin Stripe 19 in x 3.5 in |
Rear Wheel | Sport Contrast Cut with Indian Red Pin Stripe 16 in x 5 in |
Front Tire | Metzeler Cruisetec 130/60B19 66H |
Rear Tire | Metzeler Cruisetec 180/60R16 80H |
Wheels | Black, Slotted 5-Spoke Cast Aluminum |
Overall Vehicle Size | 39" w x 98.5" l x 53" h |
Rake / Trail | 25° / 5.9" |
Wheelbase | 65.7 in (1,668 mm) |
Seat Height | 26.5 in (672 mm) |
Ground Clearance | 5.4 in (137 mm) |
Lean Angle (Left) | 31 |
Lean Angle (Right) | 31 |
Fuel Capacity | 6 gal (22.7 L) |
Bed Capacity | 299 pounds |
Seating Capacity | 0 |
Hitch Type | Standard/1.25" Receiver |
Hitch Capacity | 1,500 (680.4 kg) |
Cargo System | Integrated Front Storage Box and Lock & Ride |
Payload Capacity | 261 lbs (575 kg) |
Dry Weight | 783 lbs (355.2 kg) |
Gauges | Fairing-mounted instrument cluster featuring analog speedometer and tachometer with fuel gauge, range, odometer and current gear. 15 LED telltale indicators; cruise control enabled, cruise control set, neutral, high beam, turn signal, ABS, check engine, low tire pressure, battery, low fuel, security system, low engine oil pressure and MPH or km/h unit designation. |
Audio System | Upgraded PowerBand 2.0 Audio package Includes: 2 - 100 watt fairing speakers, 2 - 100 watt saddlebag speakers. 2- 100 watt trunk speakers. 600 watts total. |
Warranty | Factory: 2 Years, Unlimited Miles |
Lighting | LED Headlamp/Tail/Brake/Turn Signal |
Features | Standard Equipment: Remote Locking Hard Saddlebags, Power Adjustable Windshield, 37+ Gallons of Storage, Keyless Ignition, Adjustable Fairing Vents, USB Charger, Tire Pressure Monitoring System (TPMS) |
Instrumentation | Infotainment: A 7" Display Powered by RIDE COMMAND with Turn-by-Turn GPS Navigation, Customizable Gauge Screens, Bluetooth Connectivity, AM/FM Radio, Selectable Ride Modes, and More; Factory-Installed RIDE COMMAND+ Telecommunications Unit (TCU) for One-Year FREE Provides Live Weather and Traffic Overlays, Apple CarPlay, Bike Health, Bike Locator, Intuitive Destination Search, and More |
