Transmission | Semi-automatic with reverse function |
Transmission Type | Chain (final drive) |
Clutch | Wet, Multi-Plate |
Gearbox | 6-speed |
Chain Type | 2.276:1 |
Gear Ratios 1st | 2.769:1 |
Gear Ratios 2nd | 1.882:1 |
Gear Ratios 3rd | 1.500:1 |
Gear Ratios 4th | 1.273:1 |
Gear Ratios 5th | 1.125:1 |
Gear Ratios 6th | 0.966:1 |
Front Suspension | Double A-arms with anti-roll bar |
Rear Suspension | Swing arm |
Front Travel | 16 in (406 mm) |
Rear Travel | 18 in (457 mm) |
Front Shocks | Gas-charged, KYB shocks |
Rear Shocks | SACHS shock |
Front Braking System | 270 mm discs with Brembo 4-piston fixed calipers |
Rear Braking System | 270 mm disc, 1-piston floating caliper with integrated parking brake |
Parking Brake | Electrically actuated |
Front Tire | MC165/55R15 55H |
Rear Tire | MC225/50R15 76H |
Wheels | Cast Aluminum |
Front Wheel | 5-spoke, Deep Black, machined and tinted, 15 x 5 in. (381 x 127 mm) |
Rear Wheel | Deep Black, 15 x 7 in. (381 x 178 mm) |
Seat Height | 26.6 in (675 mm) |
Rake / Trail | 29° / 4.8" |
Wheelbase | 67.3 in (2 mm) |
Overall Vehicle Size | 37.6" w x 86.9" l x 45.5" h |
Ground Clearance | 4.5 in (115 mm) |
Lean Angle (Left) | 33 |
Lean Angle (Right) | 33 |
Bed Box Dimensions | 28 x 22 x 7 in (72.0 x 57.0 x 17.8 cm) |
Fuel Capacity | 7.1 gal (27 L) |
Seating Capacity | 0 |
Bed Capacity | 1000 pounds for 49-state models |
Cargo System | Lock & Ride |
Payload Capacity | 336 lbs (740 kg) |
Box Capacity | 300 lb (136 kg) |
Hitch Type | 2 in. hitch receiver |
Hitch Capacity | 1,225 lb (555.7 kg) |
Cargo Capacity | 199 lbs (439 kg) |
Storage Capacity | 6.5 gal (24.4 L) |
Towing Capacity | 1,134 lbs (2,500 kg) |
Rack Capacity (Front) | 90 lb (41 kg) |
Rack Capacity (Rear) | 180 lb (82 kg) |
Rack Capacity | Front: 120 lb (54.4 kg) / Rear: 240 lb (109 kg) |
Dry Weight | 1,642 lbs (745 kg) |
Gauges | Standard and Limited: Analog speedometer, Digital tachometer, odometer, trip meter, engine temp, low fuel lamp Limited +Tech: Digital Speedometer, Digital Tachometer, Odometer, fuel gauge, compass, ambient temperature, Gear indicator |
Magneto | 650 W |
Warranty | Factory: 2-year BRP limited warranty with 2-year roadside assistance | Extended Service Terms: B.E.S.T. terms available from 12 to 36 months with roadside assistance |
Features | Audio System: USB, Bluetooth and 1/8 in. (3.5 mm) audio inputs | Main functions: Speedometer, tachometer, odometer, trip and hour meters, fuel consumption average, gear position, ECO mode, Sport mode, temperature, engine lights, electronic fuel gauge, clock and more |
Lighting | LED Head Lights & Tail Lights, Front & Rear LED Accent Lights, Illuminated In-Cab Controls |
Instrumentation | Large panoramic 7.8 in. (19.8 cm) wide LCD color display with BRP Connect, allowing the integration of vehicle-optimized smartphone apps |
Steering | Tilt: Standard Tilt |
Cage Type | Profiled cage, ROPS approved |
Handlebars | Neken, aluminium 28/22 mm |
